LINK-MI LM-THF108 User Manual

1.Description
The LM-THF108 Fiber optic extender provides extension of VGA signals long distances over
one fiber optic cable, it supports high resolution up to 1080P, transmitter local output,
RS232 signal and external audio transmission function. The extender can use for a wide
range of applications requiring long distance transmission of high resolution with high
quality by its good stability and powerful security.
2.Features
 Transmits VGA video signals up to 10km over one fiber optic cable;
 Support video resolution up to 1920*1080P@60Hz;
 Support external stereo audio unidirectional transmission;
 Support transmitter one channel signal output;
 Support RS232 signal unidirectional transmission, baud rate self-adaptive;
 High compatibility, can auto-match source and display device;
 Built-in automatic adjustment system, make the image smooth, clear and stable;
 Built-in ESD protection system;
 Simple to install, plug and play;
3.Specifications
Parameter
Standards
Maximum pixel clock
Video
Resolution
Impedance
Interface
Format
Audio
Signal type
Interface
RS232
Signal direction
VGA Fiber Optic Extender
LM-THF108
User Manual
Description
VGA
380MHz
1920x1200@60Hz / 1920x1080@60Hz
1600x1200@60Hz / 1680x1050@60Hz
1280x1024@60Hz / 1280x1024@75Hz
1280x800@60Hz / 1280x768@60Hz
1280x720@60Hz /
1024x768@60Hz / 1024x768@75Hz
800x600@60Hz / 800x600@75Hz
75Ω
3.5mm earphone seat
44.1K,48K,96K,176K,192K
Stereo
Industrial terminal
Unidirectional
