Equipment explanation

Part name and function

Top
Infra LED
Link LED
(Green)
(Green)
Front Side
Push Switch
<Top/Front Side>
The LED's have the following meaning:
Status LED (Orange)
Flashes during data transfer.
Link LED (Green)
Lights when an OldAdHoc mode network connection is established.
Lights when an AdHoc mode network connection is established.
Lights when an Infra mode network connection is established.
Infra LED (Green)
Lights when an Infra mode network connection is established.
<Bottom>
Ethernet Address
The Ethernet (MAC) Address of the device is found on the bottom.
The last 6 digits are the product's serial number.
- If the Ethernet Address is 00:80:92:18:0E:1A (noted as 008092180E1A) then the
product's serial number is 180E1A.
PRICOM C-6400W
Users Manual CX2
Bottom
Status LED
(Orange)
Right Side
Power Connector
USB Port
Ethernet Address
(The last 6 digits are the product serial
number)
2-4
