1. About PRICOM 7000
This chapter explains about PRICOM operating environment, outline and how to connect
PRICOM to the network.
Features
- 64bit RISC CPU
- Uses Linux operating system
- Supports USB2.0
- Printing Job Management Function
- USB Network Scanner Function
- DHCP/DNS Server Function
- Multi-port; USB port x 2, Parallel port x 1
- Supports 10BASE-T and 100BASE-TX (Auto-detection)
- Popup Printer Status Monitoring
- "Quick Setup" is included in the accessory kit for easy configuration.
- "AdminManager" is included in the accessory kit.
- Printing software "JC-Print2002" is included in the accessory kit.
- USB Utility "PRICOM USB Utility" is included in the accessory kit.
- Embedded HTTP enables you to configure PRICOM via Web browser.
About PRICOM 7000
Users Manual SX
USB2 port
USB HUB
USB1 port
Parallel port
1-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRICOM 7000 and is the answer not in the manual?

Questions and answers

Related Manuals for Silex technology PRICOM 7000

Summary of Contents for Silex technology PRICOM 7000

  • Page 1 Users Manual SX 1. About PRICOM 7000 This chapter explains about PRICOM operating environment, outline and how to connect PRICOM to the network. Features - 64bit RISC CPU - Uses Linux operating system - Supports USB2.0 - Printing Job Management Function...

  • Page 2: Print Server Operating Environment

    [Required device to connect scanner to network] - USB cable - Scanner - You can connect only one scanner to PRICOM. [Supported protocol / Operating system] - Supported protocol: TCP/IP - Supported OS : Windows 2000, Windows XP About PRICOM 7000...

  • Page 3: Dhcp/Dns Server Operating Environment

    Name Service) and DDNS (Dynamic Domain Name Service). [Required environment to use DHCP/DNS server function] - The network which consists of about 20 apparatus (recommend) [DHCP server fuction] - Assign IP address [DNS server fuction] - Manage Domain name About PRICOM 7000...

  • Page 4: Parts On Pricom 7000

    Users Manual SX Parts on PRICOM 7000 Parts and Function Back Front 8. Push Switch 1. POWER LED 9. Network Port (10BASE-T/100BASE-TX) 2. USB1 LED 10. USB1 Port 6. 10B LED 3. USB2 LED 7. 100B LED 11. USB2 Port 4.

  • Page 5: Push Switch Operation

    2. The test print will be executed. - Self-diagnostic report is available only with printers with fonts connected to parallel port. - When there are any NG in the self-diagnostic report, please inquire to our customer support center. About PRICOM 7000...

  • Page 6: Install Hardware

    NOTE NOTE NOTE NOTE NOTE - The connector of a USB cable has 2 different forms. The USB port of PRICOM 7000 is Type A. Please check the proper form for the connection. Type A Type B About PRICOM 7000...

  • Page 7: Connect Pricom To The Network

    4. 4. 4. 4. 4. Connect the power supply to PRICOM and switch on the printer. Check for the printer proper function. - Please do not use AC adapters other than AC adapter of PRICOM attachment. It causes failure. About PRICOM 7000...
