- Page 1 Roger Access Control System MCT82M and MCT84M Operating Manual Product version: 1.0 Firmware version: 1.1.18 or newer Document version: Rev. D...
-
Page 2: Design And Application
22.06.2021 1. D ESIGN AND APPLICATION MCT82M and MCT84M are series of access terminals dedicated to RACS 5 system. Depending on their versions, devices enable identification of users by PINs and/or 13.56 MHz MIFARE® Ultralight/Classic proximity cards. Both MCT82M and MCT84M are connected to access controller through RS485 interface. - Page 3 MCT82M MCT84M Operating Manual.doc 22.06.2021 450m 600m Fig. 1 MCT supply from MC16 access controller Fig. 2 MCT supply from dedicated power supply unit RS485 bus The communication method with MC16 access controller is provided with RS485 bus which can encompass up to 16 devices of RACS 5 system, each with unique address in range of 100-115.
-
Page 4: Function Keys
MCT82M MCT84M Operating Manual.doc 22.06.2021 the RACS 5 system guarantees proper communication in a distance of up to 1200 meters as well as high resistance to interferences. Note: Do not use more than single pair in UTP cable for RS485 communication bus. - Page 5 (VISO). Inputs Terminals in –IO version e.g. MCT82M-IO offer 3 general purpose parametric inputs of NO, NC, 3EOL/DW/NO and 3EOL/DW/NC type and 1 input internally connected to tamper contact. Input types and electric parameters such as response time and parametric resistors are defined within low level configuration (VISO v2 or RogerVDM).
- Page 6 Main Board of a controller in VISO software navigation tree. Outputs Terminals in –IO version e.g. MCT82M-IO offer 2 transistor open collector type outputs (15V/150mA rated) and 1 relay output with NO/NC contacts (30V/1.5A DC/AC rated). Electric parameters such as polarity are configured within low level configuration (VISO v2 or RogerVDM).
-
Page 7: Installation
MCT82M MCT84M Operating Manual.doc 22.06.2021 2. I NSTALLATION Table 5. Screw terminals Name Description 12VDC power supply Ground RS485 bus, line A RS485 bus, line B IN1 input line IN2 input line IN3 input line IO1 output line IO2 output line... - Page 8 MCT82M MCT84M Operating Manual.doc 22.06.2021 Fig. 5 MCT82M installation 8/18...
- Page 9 MCT82M MCT84M Operating Manual.doc 22.06.2021 Fig. 6 MCT84M installation 9/18...
- Page 10 MCT82M MCT84M Operating Manual.doc 22.06.2021 Note: MCT82M enclosure consists of front panel and back panel. New device is assembled with a standard back panel, but additional free of charge, extended back panel is included. This panel can be used when connection cable has to be hidden and no flush mounting box is available.
- Page 11 MCT82M MCT84M Operating Manual.doc 22.06.2021 Fig. 8 Typical connection diagram for the –IO version terminal and MC16 access controller 4. C ONFIGURATION The purpose of low level configuration is to prepare device for operation in RACS 5 system. In case of RACS 5 v1 system the address of device must be configured by means of RogerVDM software or by manual addressing before connection to MC16 controller.
- Page 12 MCT82M MCT84M Operating Manual.doc 22.06.2021 4. Start RogerVDM program, select MCT device, firmware version, RS485 communication channel and serial port with RUD-1 interface. 5. Click Connect, the program will establish connection and will automatically display Configuration tab. 6. Enter unoccupied RS485 address in range of 100-115 and other settings according to requirements of specific installation.
- Page 13 MCT82M MCT84M Operating Manual.doc 22.06.2021 LED SYSTEM flash after card Parameter enables short flash of LED SYSTEM (orange) when card is read read. Range: [0]: No, [1]: Yes. Default value: [1]: Yes. LED SYSTEM flash after key Parameter enables short flash of LED SYSTEM (orange) when key is press pressed.
- Page 14 MCT82M MCT84M Operating Manual.doc 22.06.2021 Default value: [0010]: Number 40bits. Long card read time [s] Parameter defines long card read time. When set to 0 then long read is disabled. Range: 0-64. Default value: 0. Long key press time [s] Parameter defines long press time for such key types as [*], [#] and [F1] - [F4].
-
Page 15: Manual Addressing
Parameter defines 6 bytes (12 HEX digits) key for accessing sector where PCN is stored. Note: Table 6 includes summary of parameters for all versions of MCT82M and MCT84M terminals. For instance keypad settings are not available for –BK version of terminals i.e. terminals without keypad. -
Page 16: Firmware Update
The purpose of high level configuration is to define logical functioning of the terminal which communicates with the MC16 access controller and it depends on applied scenario of operation. The example of access control system configuration is given in AN006 application note which is available at www.roger.pl. 5. F IRMWARE UPDATE The firmware of device can be changed to newer or older version. -
Page 17: Ordering Information
Environmental class (according humidity: 10 to 95% (no condensation) 50133-1) Dimensions H x W x D MCT82M series: 85 x 85 x 22(37) mm MCT84M series: 130 x 45 x 22 mm Weight MCT82M series: ~100g MCT84M series: ~100g Certificates 7. - Page 18 MCT82M MCT84M Operating Manual.doc 22.06.2021 This symbol placed on a product or packaging indicates that the product should not be disposed of with other wastes as this may have a negative impact on the environment and health. The user is obliged to deliver equipment to the designated collection points of electric and electronic waste.
