700 U (C) User Manual
1.4

Display Indicators

1.
2.
3.
4.
5.
6.
7.
8. LCD Screen:
Service Indicator:
When a call is in progress,
When the icon is not shown on the display the handset is in standby
mode.
Signal Strength:
Indicates the current signal strength. When the phone is in a service area
lines are displayed to signify signal strength. More lines mean better
signal strength. Signal strength is symbolize as follows:
Toll Call Lock:
Indicates the toll or long distance call lock is activated.
Mute Ringing Tone:
Indicates the handset ringer has been disabled.
Keypad Lock:
Indicates the keypad lock is activated.
Alarm:
Indicates the alarm is activated.
Battery:
Indicates the battery charge level status in 4 steps:
- Fully charged
- Half Full
- Low, not much power left
- Requires charging
Displays the phone numbers and text that have been entered.
Before Using Your Phone 1-5
is displayed to show off hook status.
