1.4 Display Indicators

The C1100 display includes four primary areas: the top annunciator row,
the context area, the main area, and the soft key area

1.4.1 Annunciators

The annunciators occupy the top row of the display area and include:
Indicates the current signal strength. The higher the bar, the
stronger the signal
Indicates the battery charge level. The more blocks, the longer the
battery life
Indicates the battery is fully charged when an adapter is plugged into
the phone
Indicates voice call is active
Indicates that there is one or more voicemails present on the system
Indicates one or more normal unread text messages (including pages)
Indicates one or more urgent unread text messages (including
pages)
Indicates vibrate mode is on. Also appears if the master volume is set
to "On + Vibrate" or "Off + Vibrate"
Indicates silent mode is on. Also appears if the ringer volume is set to
Getting Started
9
