UTStarcom F1000G Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
_______________________________________
Copyright Statement: "© 2005 UTStarcom, Inc. All rights reserved. No
part of this publication may be reproduced in any form or by any means
without the prior written permission of UTStarcom, Inc."
Warranty Language: "The contents of this manual, whether in whole or in
part, do not constitute any express or implied warranty with respect to any
products of UTStarcom, Inc., or its affiliates."
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F1000G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UTStarcom F1000G

Summary of Contents for UTStarcom F1000G

  • Page 1 _______________________________________ Copyright Statement: “© 2005 UTStarcom, Inc. All rights reserved. No part of this publication may be reproduced in any form or by any means without the prior written permission of UTStarcom, Inc.” Warranty Language: “The contents of this manual, whether in whole or in part, do not constitute any express or implied warranty with respect to any products of UTStarcom, Inc., or its affiliates.”...

  • Page 2: Table Of Contents

    Table of Contents ........1 ANDLING THE HONE ATTERY AND HARGER ................2 ANDLING THE HONE ..............4 ANDLING THE ATTERY ..............5 ANDLING THE HARGER 1. GETTING STARTED ............6 1.1 P ..............6 ACKAGE ONTENTS 1.2 P ..............7 HONE PECIFICATIONS 1.3 H ..............8 ANDSET ESCRIPTION 1.4 D...
  • Page 3 2.10 C ...........23 URRENT ROFILE HORTCUT 2.11 V ...............23 IBRATION HORTCUT 2.12 K ................24 EYPAD 3. PHONEBOOK (NAMES) ..........25 3.1 S ..................25 EARCH 3.1.1 Edit ....................26 3.1.2 Delete Entry ...................26 3.2 A .................26 NTRY 3.3 D ................28 ELETE NTRY 3.3.1 One by One ...................28 3.3.2 All....................28 3.4 G...
  • Page 4 4.3.6 Set Security ...................45 4.3.7 Input Method..................47 4.4 T ..................48 OOLS 4.4.1 Calculator ..................48 4.4.2 Calendar ..................49 4.4.3 Alarm .....................49 4.4.4 Time Zone..................50 4.4.5 DST Setting ...................51 4.4.6 Time Format...................51 4.5 W ................52 ETTINGS 4.5.1 Net Search..................52 4.5.2 WiFi Config ..................52 4.5.3 Network Parameter ................55 4.5.4 Signal Protocol................57 4.6 N...
  • Page 5 6. TROUBLESHOOTING........... 71...

  • Page 7: Handling The Phone, Battery And Charger

    Safety Precautions Handling the Phone, Battery and Charger DANGER Only use the battery and charger specified for the phone. Failure to do so can result in damage to the phone, electric shock or fire CAUTION Do not store or operate the phone or charger in hot, damp, or dusty areas, which can damage electrical and mechanical components.

  • Page 8: Handling The Phone

    Safety Precautions Handling the Phone This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference This device must accept any interference received, including interference that may cause undesired operation DANGER This phone has been tested and found to comply with the limits for a Class B digital device, pursuant to Part...
  • Page 9 Do not use the phone while operating a vehicle CAUTION Changes or modifications not expressly approved by UTStarcom, Inc. could void the user’s authority to operate the phone Keep all storage media (magnetic cards, floppy disks, credit cards, etc.) away from the phone. Close...

  • Page 10: Handling The Battery

    Safety Precautions Handling the Battery DANGER Do not dispose of the battery pack in a fire. It may explode. Check with local waste management codes for disposal instructions Do not force the battery pack into the phone. Improper installation can cause malfunctions or damage the battery pack.

  • Page 11: Handling The Charger

    Safety Precautions Handling the Charger DANGER Only use a power source that provides the appropriate voltage (AC100~240 V) for the charger. An unsuitable power source can result in damage to the charger, electric shock or fire Do not use the charger if the power supply cord or plug is damaged or frayed (exposed or broken wires, etc).

  • Page 12: Getting Started

    Please check the package contents by comparing them with the following list. If you find anything missing or if the documentation set is incomplete, contact your local phone dealer immediately Model F1000G (with one battery) Charger (one) User manual (one)

  • Page 13: Phone Specifications

    Getting Started 1.2 Phone Specifications Dimensions About 107.8 x 44 x 23.5 (L×W×H) mm Weight Approximately 100g Battery DC 3.6V 1500mAh Li-ion battery Charger Input: 100~240V AC, 50~60Hz Output: 5.2V DC, 600mA Charger Weight Approximately 80g Charging Time 3~4 hours Standby Time 50~100 hours Talking Time...

  • Page 14: Handset Description

    Getting Started 1.3 Handset Description 1. Fixed antenna 2. Earpiece 3. LCD Screen Navigation Key: This key is used to scroll up and down through menu lists Left Soft Key: This key is used to perform the function indicated on the screen above...
  • Page 15 Getting Started Talk Key: This key is used to make or receive a call. It can also be used to access outgoing call logs in standby mode Number Keypad: These keys are used to enter numbers and characters * Key/Switch Key: This key is used to key in “*”...

  • Page 16: Display Indicators

    Getting Started 1.4 Display Indicators 4 5 6 Shows the current signal strength. The higher the bar, the stronger the signal Strong Weak Indicates a new voice mail has been received Indicates the keypad is locked Means the Ring Mode is set to Mute; if the Ring Mode is set to Ringing, will be displayed Means the Ring Mode is set to Vibration...

  • Page 17: Charge The Battery

    Getting Started 8. Content Display Area: Shows phone numbers, characters, etc. 9. Soft key function display area: Shows the functions of the left soft key and the right soft key 1.5 Charge the Battery When the battery power is low and needs recharging, the battery indicator will flash continuously, and the phone will sound a low battery alarm (if the alert tone is set to On), remin...

  • Page 18: Replace The Battery

    Getting Started 3. When the battery indicator bar stops scrolling, charging is complete. The text “Fully Charged!” is also display d on th LCD creen, phone is off The pho ne takes about 3~4 hours to charge and the exact time may vary depending on the circumstances With your phone turned off, charge your new battery for 4 hours before its first use...
  • Page 19 Getting Started 3. Remove the old battery Disconnect the cord by firmly gripping the connector (not the battery connection wire) and pulling gently as illustrated Black Yellow 4. Install the new battery Connect the cord of the new battery by firmly inserting the connector into its place.

  • Page 20: Conventions Used In This Manual

    Getting Started 5. Replace the battery cover until it clicks into place 1.7 Conventions Used in this Manual In this manual, “press the key” means to release the key after you press it; “press and hold the key” means to press the key for over 2 seconds before releasing it The text displayed on the screen is indicated in bold in this manual, for example Menu...

  • Page 21: Access Menu /List Options

    Getting Started 1.8 Access M u/List Options A variety of options are available for the menus and lists, such as: Menu Names or example, to access Settings Answer Mode, follow the steps below: 1. In standby mode, press the left s oft key (Menu) 2.

  • Page 22: Basic Operations

    Basic Operations 2. BASIC OPERATIONS 2.1 Switch the Phone On/Off Press and hold the power key . The phone will display the power-on/off animation If the PowerOn Code function is active, after switching on the phone, enter the security code (with each input displayed as *) and press the left soft key (Ok).

  • Page 23: Answer A Call

    Basic Operations , you can quickly call that phone number: 1. In standby mode, press and hold the corresponding speed dial key to automatically display the phone number 2. Press to call the number For details of speed dial settings, refer to page 29 “Speed Dial” 2.4 Answer a Call If the Answer Mode is set to Talk Key, press the left soft key (Answer) or the...

  • Page 24: I Ncall Operations

    Basic Operations 6 In Call Operati ns While on a call, you can perform t he following operations: 2.6.1 Hold a Call You can place an ong oing call temporarily on hold During a call, press th e left soft key (Option), and then press the left soft key (Ok) to select Hold.

  • Page 25: Make A New Call

    Basic Operations Press the left soft key (Option). Press to highlight End Held Call and press the left soft key (Ok) to end the held call Press the right soft key (Hangup) to end the current call. Then, you can press the left soft key (Option) and select Unhold to take the held call off hold Press the...

  • Page 26: Conference Call

    Basic Operations 2.6.4 Conference Call If the Three Way Call function is active, after making a new call with the original call on hold (refer to page 19 “Make a New Call”), you can make a conference call with both parties. Press the left soft key (Option).

  • Page 27: Mute The Microphone Volume

    Basic Operations 2.6.6 Mute the Microphone Volume During a call, press the left soft key (Option). Press to highlight Mute and press the left soft key (Ok). The microphone volume will be set to mute To resume the volume, press the left soft key (Option).

  • Page 28: Store A Phone Number

    Basic Operations 2. There are six volume levels. Press to increase or decrease the volume If the volume is at the highest level, the volume level will not change when is pressed; if the volume is at the lowest level, the volume level will not change when is pressed 3.

  • Page 29: Custom Functions Shortcut

    Basic Operations Press to display the latest received call. Press to scroll through other received call records Press to display the latest missed call. Press to scroll through other missed call records After the intended record is displayed, you can press to call the number To perform other operations with the record, press the left soft key...

  • Page 30: Keypad Lock

    Basic Operations “Off”. will be displayed Press and hold again to resume ring mode, keypad tone and alert tone in the current profile For detailed operations, refer to page 38 “Ring Mode” 2.12 Keypad Lock The keypad lock prevents the keys from being accidentally pressed, resulting in unintentional operations In standby mode, press and hold to lock the keypad.

  • Page 31: Phonebook (Names)

    Phonebook (Names) 3. PHONEBOOK (NAMES) You can store frequently used phone numbers and names in the phone memory (phonebook). The phonebook can store up to 200 entries. Each entry may contain a name, phone number and group information You can enter the phonebook in either of the following ways: In standby mode, press the right soft key (Names) In standby mode, press the left soft key...

  • Page 32: Edit

    Phonebook (Names) 2. The letter/digit just entered will be underlined. After you have entered the intended letter/digit, press the appropriate number key to input the next letter/digit. If the next letter/digit and current letter/digit share the same key, wait for one second to input the letter/digit again To delete the last entered letter/digit, press the right soft key (Clear);...
  • Page 33 Phonebook (Names) 1. Key in the name, and press the left soft key (Ok) You can enter a maximum of 20 English letters or 10 Chinese characters (refer to page 67 “Input Method”) 2. Enter the phone number (24 digits maximum), and press the left soft (Ok) The phone number cannot be left blank;...

  • Page 34: Delete Entry

    Phonebook (Names) 3.3 Delete Entry Delete Entry You can select from the following options to delete entries one by one or all at once 3.3.1 One by One Delete Entry One by one When you access this option, the phonebook entry list will be displayed. Enter the first letter(s)/digit(s) of the intended entry (name).

  • Page 35: Ring Tone

    Phonebook (Names) 3.4.1 Ring Tone Select this option to specify a ring tone for the particular group category Press to highlight and sample the ring tone options. Then press the left soft key (Ok) to complete your selection Note: The Blacklist only has a Browse function because the phone will automatically reject any call from this group.

  • Page 36: Memory

    Phonebook (Names) Press to highlight the entry, and press the left soft key (Ok) to assign the number to the key If a phone number has been assigned to the key, the corresponding name will be displayed. To change or cancel the setting for this key, press the left soft key (Option), and then select Edit or Cancel Note: If the record for a speed dial key is modified in the phonebook,...

  • Page 37: Menu

    Menu 4. MENU In standby mode, press the left soft key (Menu) to access the menu. Press to reach the desired submenu, and press the left soft key (Ok) to access the submenu 4.1 Call Log Call Log Your phone records missed, received and dialed calls as well as their call durations In standby mode, you can press to quickly access...
  • Page 38 Menu When a call log is displayed, press the left soft key (Option). The following options will be available: 4.1.1.1 Edit After you access this option, the caller’s phone number will be displayed. You can edit the phone number, and then save or dial the edited number: Save Number After editing the number, press the left soft key (Save).

  • Page 39: Received Log

    Menu 4.1.2 Received Log Call Log Received Log This option enables you to view the last 20 received calls After you access this option, the phone will display the information of the most recently received call Received 1: the caller’s phone number or name (if the number is stored in the phonebook).

  • Page 40: Dialed Log

    Menu 4.1.2.4 Duration Select this option to view the duration of the received call. 4.1.3 Dialed log Call Log Dialed Log This option enables you to view the last 20 dialed calls After you access this option, the phone will display the information of the most recent outgoing call Dialed 1: the dialed phone number or name (if the number is stored in the phonebook).

  • Page 41: Delete Log

    Menu Note: The phone number and name cannot be identical to those of an existing phone book entry. Otherwise, the text Exists will be displayed after you enter the name and press the left soft key (Ok). Dial Number After editing the number, press to call the displayed number 4.1.3.2 Time Select this option to view the time the call was dialed...

  • Page 42: Duration

    Menu 4.1.5 Duration Call Log Duration This option enables you to view the approximate duration of received calls, dialed calls, or the duration of all calls After accessing this option, press to view the duration of received calls (Received), dialed calls (Dialed), as well as the duration of all calls (Total Time).

  • Page 43: Profiles

    Menu 4.2 Profiles Profiles This submenu enables you to customize the phone alert settings to suit a variety of environments When you access this submenu, the profile list will be displayed; the current profile will be highlighted. You can customize each profile, and activate the one that suits your environment.
  • Page 44 Menu There are two volume levels: High and Low. Press to reach the desired volume level, and press the left soft key (Ok) to complete the operation Ring Mode This function enables you to define how the phone will notify you of incoming calls The available options include: Ringing, Vibration and Mute.

  • Page 45: Meeting

    Menu Alert Tone If this function is activated, a warning tone will sound when the battery power is low Select On or Off to activate or deactivate this function 4.2.2 Meeting Profiles Meeting This profile is suitable for meeting environments. You can preset this option to meet your needs by following the same steps specified in “Standard”...

  • Page 46: Settings

    Menu 4.3 Settings Settings From this submenu, you can perform various phone settings 4.3.1 Scheme Settings Scheme When this option is highlighted, the current setting will be displayed in the adjacent bubble. After accessing this option, you can select from the following options: 4.3.1.1 Static Picture The standby display will become static after you set this option...

  • Page 47: Date/Time

    Menu Default The standby display will change every hour in the default picture sequence after you select this option User Edit This option enables you to specify the picture or text for each hour (Picture1~Picture24) Select from the options Picture1~Picture24, and then edit text or select a picture by following the same operations specified in “Static Picture”.

  • Page 48: Answer Mode

    Menu After accessing the option, enter a date from 2004-01-01 to 2019-12-31, and then enter the time in the corresponding time format. Press the left soft key (Ok) to complete the operation When you key in the date or time, you can press to move the cursor and modify the number 4.3.3 Answer Mode...

  • Page 49: Display

    Menu 4.3.5 Display Settings Display You may set the display for the LCD screen as follows: 4.3.5.1 Backlight Settings Display Backlight When you highlight this option, the current setting will be displayed in the adjacent bubble If the Backlight is not set to Off, the LCD screen and keypad will light when you press keys or the phone receives a call The following options are available: Select this option to deactivate the backlight...
  • Page 50 Menu reaching the desired contrast level, press the left soft key (Ok) to complete the operation 4.3.5.3 Screen Saver Settings Display Screen Saver When you highlight this option, the current setting will be displayed in the adjacent bubble If the Screen Saver is not set to Off, the clock screen saver will be displayed after the phone has been in standby mode for one minute.

  • Page 51: Set Security

    Menu 4.3.6 Set Security Settings Set Security This option enables you to set the security level to protect your phone After accessing this option, you will be prompted to enter the security code. Key in the security code and press the left soft key (Ok).
  • Page 52 Menu 4.3.6.3 Reset All Select this option to restore your phone’s default settings When you access this option, “Reset All?” will be displayed. Press the left soft key (Ok) to complete the operation This operation will not delete the phonebook entries or call logs. It cannot change the phone’s date and time either Phone Default Settings Functions...

  • Page 53: Input Method

    Menu Functions Default Settings Alarm (On/Off) Alarm (Set Time) 08:00 Alarm (Snooze) Current Time Zone New York Time Format 24 Hour Profiles Default Settings Profile User Standard Meeting Outdoor Options Define Ring Volume High High High Ring Mode Ringing Vibration Ringing Ringing Ring Tone...

  • Page 54: Tools

    Menu 4.4 Tools Tools From this submenu, you can use the Calculator, view the Calendar, set the Alarm, change the current Time Zone, enable DST (Daylight Saving Time) or set Time Format 4.4.1 Calculator Tools Calculator This function enables you to add, subtract, multiply and divide 1.

  • Page 55: Calendar

    Menu A maximum of 9 digits (including minus sign and decimal point) can be entered at one time If the formula violates mathematical principles (for example, 5/0), Error will be displayed If the absolute value of the calculation result exceeds 999,999,999, Overflow will be displayed 4.4.2 Calendar Tools Calendar...

  • Page 56: Time Zone

    Menu After accessing this option, select On or Off to activate or deactivate the alarm function 4.4.3.2 Set Time Tools Alarm Set Time Select this option to set the alarm time. Enter the time in the corresponding time format, and then press the left soft key (Ok) to complete the operation When you key in the time, you can press...

  • Page 57: Dst Setting

    Menu 4.4.5 DST Setting Tools DST Setting This function enables you to activate or deactivate Daylight Saving Time (DST). When you highlight this option, the current DST setting will be displayed in the adjacent bubble After accessing this option, select On or Off to activate or deactivate the DST function 4.4.6 Time Format Tools Time Format...

  • Page 58: Wifi-Settings

    Menu 4.5 WiFi-Settings WiFi-Settings From this submenu, you can perform the following WiFi settings Note: After completing WiFi settings, switch off the phone and then switch it on, in order that the changed WiFi settings can take effect 4.5.1 Net Search WiFi-Settings Net Search This option enables you to search available APs (10 maximum) for the phone.
  • Page 59 Menu 4.5.2.1 Authentication WiFi-Settings WiFi Config Authentication This option enables you to set the WiFi authentication mode. When you highlight this option, the current setting will be displayed in the adjacent bubble After accessing this option, you can select Null or Shared Key 4.5.2.2 SSID &...
  • Page 60 Menu Null Select this option to set the WEP key to null 64bit Select this option to enter a 64bit WEP key. Edit the WEP key and press the left soft key (Ok) to complete the operation Ensure that the WEP key consists of five ASCII characters or ten hexadecimal characters 128bit Select this option to enter a 128bit WEP key.

  • Page 61: Network Parameter

    Menu Activate Select this option to connect to the AP according to the connection profile. If the connection fails, the phone will try to connect to other connection profiles’ APs. If the phone fails to connect to all these APs and the Auto Scan function is active, the phone will try to search and connect to another available AP (Refer to page 55 “Auto Scan”) 4.5.2.3 Auto Scan...
  • Page 62 Menu 4.5.3.2 IP WiFi-Settings Network Parameter IP This option enables you to perform IP settings When you highlight one of the following options, its current setting will be displayed in the adjacent bubble Note: Only when DHCP is disabled, can the IP option be available. Otherwise, when you select this option, Please disable DHCP will be displayed IP Address...

  • Page 63: Signal Protocol

    Menu of the following options, its current setting will be displayed in the adjacent bubble Primary DNS Server IP Address Select this option to set the IP address of the local primary DNS server After accessing this option, key in the IP address, and press the left soft (Ok) to complete the operation Secondary DNS Server IP Address Select this option to set the IP address of the local secondary DNS server...
  • Page 64 Menu 4.5.4.1 SIP WiFi-Settings Signal Protocol SIP This option enables you to set the SIP protocol. The following options are available When you highlight one of these options, its current setting will be displayed in the adjacent bubble SIP Register Server Mode Select this option to set the SIP register server mode After accessing this option, you can select IP or DNS SIP Register Server Domain Name...
  • Page 65 Menu SIP Outbound Proxy Select this option to set the SIP outbound proxy After accessing this option, you can select IP or DNS SIP Outbound Server Domain Name Select this option to set the SIP outbound server domain name After accessing this option, enter the domain name, and press the left soft (Ok) to complete the operation SIP Outbound Server IP Address Select this option to set the SIP outbound server IP address...
  • Page 66 Menu left soft key (Ok) to complete the operation SIP Password Select this option to set the SIP password After accessing this option, follow the prompt to enter the security code and press the left soft key (Ok). Enter the SIP password (0~32 alphanumeric characters), and press the left soft key (Ok) to complete the operation...
  • Page 67 Menu Voice Mail Access Number Select this option to set the voice mail access number After accessing this option, key in the access number, and press the left soft key (Ok) to complete the operation The default voice mail access number is “*123”...

  • Page 68: Network Service

    Menu 4.6 Network Service Network Service From this submenu, you can set the following network services: 4.6.1 Call Waiting Network Service Call Waiting This option enables you to set the Call Waiting function 4.6.1.1 Per Call Basis Network Service Call Waiting Per Call Basis Select Enable or Disable to activate or deactivate the per call basis Call Waiting function 4.6.2 Call Transfer...

  • Page 69: Three Way Call

    Menu 4.6.2.3 Consult Network Service Call Transfer Consult If this option is selected, you need to announce th e transfer after the transferred-to party answers your call. Then, press the left soft key (Transfer) to transfer the intended call 4.6.2.4 Blind & Consult Network Service Call Transfer Blind &...

  • Page 70: Caller-Id Block

    Menu 4.6.5 Caller-ID Block Network Service Caller-ID Block If this function is active, when you dial a call, your phone number will not be displayed on the called party’s phone. When this option is highlighted, the current setting will be displayed in the adjacent bubble After accessing this option, select On or Off to activate or deactivate this function 4.6.6 Repeat Dial on Busy...

  • Page 71: Misc

    Menu 4.7 MISC MISC From this submenu, you can perform the following operations: 4.7.1 Vendor Information MISC Vendor Information Select this option to view the vendor information. Press to highlight the desired option: Vendor Name, Enterprise Code, Model Name and Version, and then press the left soft key (Ok) to view the corresponding information...

  • Page 72: Local Tftp Update

    Menu 4.7.4 Local TFTP Update MISC Local TFTP Update This option enables you to perform local TFTP update After you select this option, the phone will display a notice for the local TFTP update. Press to browse through the information. Press the left soft key (Update) to initiate the local TFTP update process Note: The phone will spend a long time completing the local TFTP...

  • Page 73: Input Method

    Input Method 5. INPUT METHOD This phone supports five input methods, including PinYin, Sim Stroke, English, Letter and Digit in order to provide easy input for letters and digits in text editing mode 5.1 Switch Input Method When you enter text-editing mode, the last active input method is displayed.
  • Page 74 Input Method 1. To enter letters, press one time for the letters labeled on the respective key; a word matching the input letters will be displayed automatically - When you enter the first letter of any English word, “*” will be displayed (except ).

  • Page 75: Letter

    Input Method 5.4 Letter Switch to Letter input method; will be displayed at the lower left corner of the screen 1. Press to enter the corresponding letter labeled on the respective key. To input a letter, press the corresponding key repeatedly until the letter appears For example: if you press repeatedly, the following letters...

  • Page 76: Digit

    Input Method 5 Digit itch to d it input method; will be displayed in the lower left corner of the screen To enter digits, press the co esponding number keys Press to switch input methods...
  • Page 77 Troubleshooting 6. TROUBLESHOOTING When using this phone, if you run into malfunctions, please refer to the following troubleshooting techniques before requesting help: Symptom Diagnosis Solution Have you pressed Press and hold held more than more than The phone seconds? seconds cannot be battery connector...
  • Page 78 Troubleshooting Symptom Diagnosis Solution The battery charger properly Connect the charger cannot be connected to the phone? and phone correctly charged (The battery Connect the charger Is the charger connected to a indicator to a 100~240V AC 100~240V AC wall outlet? bar does wall outlet correctly not scroll)
