Phone Spec - UTStarcom UTS 700 U User Manual

1-2 Before Using Your Phone

1.2 Phone Spec

Transmission power
Battery
Size
Weight
Charger
Charging time
Continuous standby time
Note: The length of standby time the battery can supply power is determined by the
telephone usage. The following actions or situations can consume more power
and reduce the standby time.
Approximately 10mW on average
DC 3.6V Ni-MH battery, at least 500mAh
118×44 ×27mm (L×W×H) (excluding antenna)
Approximately 110g (including battery pack)
Input: AC 220V±10%, 50Hz or 110VAC ±10%, 60Hz
Output: DC 4V, 225mA(CC mode)/6.1V 30mA (CV mode)
Power consumption: about 2W
Approximately 3.5 hours
48~250 hours
Table 1-1: Phone Specification
Migration to areas where signal strength is weak.
Moving through the service area.
Talking on the phone for long periods of time.
Ringing volume is set to the maximum.
Earpiece volume is set to the maximum.
Leaving the phone in hot or cold places such as a car will reduce the
capacity and life of the battery. A phone with a hot or cold battery may
temporarily not work even when the battery is fully charged.
Repeated changing of phone parameters. (i.e. Adding or deleting entries
to/from the phonebook feature)
700 U (C) User Manual
