4 - PRODUCT INSTALLATION

4.1 - Installation

Before starting the installation, make sure that the product is intact
and that the packaging contains all the components shown in Fig.3.
Make sure that the mounting area is compatible with the overall
dimensions (Fig.1).
Check the allowed opening angle according to the fixing points of the
brackets in Fig.4 and in the diagram in Fig.5.
Fig.6 is an example of a typical system:
- Operators (1)
- Photocells (2)
- Posts for photocells (3)
- Flashing light with integrated aerial (4)
- Key or digital switch (5)
Mounting
Measure the value C (Fig. 4) = distance between the rotation fulcrum
of the leaf and the pillar surface where the rear bracket will be fixed.
Move manually the leaf up to the opening required (maximum 120°):
establish the value of the maximum opening angle of each leaf.
Mark on the diagram in Fig.5 the value C and trace an horizontal
line up to intersect the area that includes the angle value measured
before.
Trace some vertical lines on the intersection points between the
horizontal line and the area in order to find the useful values for the
dimension A (fig. 4).
Chose the value A in this range.
Mark on the pillar the value A and trace a vertical line in correspon-
dence (Fig.7a).
4.2 - Adjusting the mechanical limit switch in opening
Unscrew the cover screws (Fig.12a). Raise the back by about 1 cm
then slide it out forwards (Fig.12b).
WARNING
The lights on the cover are connected by two wires, discon-
nect the terminal or lay carefully the cover upside-down on the
external part (Fig.13).
Loosen the screw of the mechanical limit switches up to when they
can slide (Fig.14).
4.3 - Electrical connections
Insert the supply cable (Fig.17). Connect the wires of the supply
cable to the terminal following the electrical drawing in Fig. 18.
Proceed with the other connections following the control unit's
4.4 - Mechanical and electronic connections of the second motor
In case of installation of the second motor, follow the above mentioned instructions for the mechanical mounting, for the electrical connec-
tions refer to the Fig.21.
4.5 - Replacing led
Switch-off the power supply.
Open the cover as shown on paragraph 4.2.
By using a screwdriver, release the bottom screw of the cover
(Fig.19a).
Remove the mask and pull out the led band (Fig.19b) .
Mounting the motor bracket to the pillar
Draw a horizontal line on the pillar in line where the leaf bracket
should be fixed (Fig.7b).
Position the bracket so that the inside of the bottom edge is alig-
ned with the horizontal line shown in Fig. 7b and fix it with suitable
screws and washers (not supplied) (Fig.7c).
Secure the gearmotor to the post bracket using the screw and nut
provided (Fig.8). The motor can be turned in this phase to simplify
the electrical connections (4.3 Electrical connections).
WARNING
An off-axis mounting can cause malfunctioning and damage
the automation system.
Mounting the motor bracket
Fix the curved arm to the motor arm using the pin and stop ring.
Fix the gate bracket to the curved arm using the pin but without the
stop ring (Fig. 9).
Move the gate leaf up to the maximum opening position. Release
the gearmotor (Fig.10)
Completely extend the arms, position the curved arm next to the leaf
of the gate and place the gate bracket on it. Holding with one hand
the bracket in contact with the leaf, try to make a complete opening
and closing movement (Fig. 11a).
Fix the gate bracket to the leaf with suitable screws (not supplied)
and fix the pin using the stop ring (Fig. 11b).
WARNING
An off-axis mounting can cause malfunctioning and damage
the automation system.
Release the gearmotor and open manually the leaf up to the
requested opening position.
Insert the pin completely into the first free hole close to the leaf
(Fig.15).
Move the mechanical stop up to the stop limit on the pin head
(Fig.16a) and screw again the mechanical stop (Fig.16b).
In order to adjust the stop in opening, move the leaf up to the
requested opening position and insert the pin into the first free hole
opposite to the leaf.
Move the mechanical stop on the stop limit on the pin head (Fig.16a)
and screw it again (Fig.16b).
instructions.
Replace the cover to its original position and fasten the two fixing
screws.
Disconnect the plug connector (Fig.20a).
Connect the new led stripe and insert them into the mask.
Insert the mask by placing first the seal side and then fastening it
with the screw (Fig.20b).
