Sununo Plus Series
5.3 AC Side Connection
Outside Diameter of the
Cross-sectional Area of Cables（mm²）
Cables（mm）
Scope
Recommended Value
4.0-6.0
4.0
4.2~5.3
Table 5.2 Recommended Specifications of AC Cables
5.3.1 Feed the AC cable through the AC waterproof hole.
Figure 5.3 Thread the cables
5.3.2 Connect the cables according to connection marks of L, N and PE.
Figure 5.4 Connect the Cables
5.3.3 Secure all parts of the AC connector tightly.
Figure 5.5 Screw the Connector
- 26 -
