Chapter 2. Specifications and requirements

See the appendix for additional specifications.

Appliance specifications

All RAM is PC4-17000 DDR4 ECC SDRAM.
Table 2. System components in the appliance
CPUs
SDRAM (GB)
Intel Xeon
2×16
E5-2620 v4
8x16*
* with feature AJEQ
** drives must be ordered/installed in sets of six
Note: Extra Networking Options
The appliance can support another networking card to provide more networking ports. These ports are
found top-center in a card-slot on the rear of the appliance.

Requirements

Cabling
Table 3. Cabling requirements for the appliance
Cable
Power Cords
Optical Fiber Cables
Direct attach copper
cables
1000BASE-T Copper
Cables

System diagram

The following figures show the appliance schematics.
© Copyright IBM Corp. 2016, 2018
Data drive
OS drive (TB)
bays
2×150 GB
12**
Type and Usage
Use only the power cords that are supplied with the appliance. Do not use another type
of cord. Do not use extension cords. If extra power cords are needed, contact IBM
Support.
Use IBM authorized enhanced small form-factor pluggable (QSFP and SFP+) transceivers
only. Optical fiber cable specifications depend on the SFP+ module used.
Any SFP+ passive or active direct attach copper cable compliant with the SFF-8431 v4.1
and SFF-8472 v10.4 specifications is supported.
Use high-quality Category 5e or 5 (CAT5e, CAT5) copper cables.
NIC ports (1
Gbps for base
PSUs
model)
2
2
NIC ports (10
Gbps for base
model)
0
3
