Mixer Taps - Zip HYDROTAP G4 series User Manual

6.4 CELSIUS HYDROTAP - OPERATION
C, CS models, rotate to dispense
Chilled water
Sparkling water
6.5 CELSIUS HYDROTAP - SAFETY LOCK
B models 3 steps to dispense boiling water
1.
2.
3.
4. Rotate control while lights flash to dispense boiling water.
SECTION 7 MIXER TAPS- CLASSIC, ARC & CUBE
7.1 MIXER TAP - OPERATION
All Zip mixers function in the following manner :
The hot water is marked with a red dot and the cold water with a blue dot.
Moving the lever away from the tap will increase the flow and towards the
tap will decrease the flow.
When the lever is moved in the direction of the blue dot, the temperature
is decreased and
when moved in
the direction of
the red dot, the
temperature is
increased.
The spout may
be swivelled,
left or right, for
convenience.
14
USER MANUAL
805846UK - ZIP HYDROTAP G4 V1.00 NOV 2017
SECTION 6 CELSIUS HYDROTAP
Boiling water mode with safety lock on
Touch x 2
+
Flash for 2 secs
Sparkling
Chilled
