IMPORTANT
Ÿ
Use a soft cloth between these parts and the floor.
Ÿ
Do not use power tools above 8 volts to assemble.
Ÿ
Do not tighten all the bolts until each part is properly assembled.
Ÿ
Keep Hex Wrench in a safe place as the bolts may need to be tightened up in the future.
STEP 1
Attach Casters underneath Base (L) with
Wood Screws for Caster, with Locking
Casters on the front. (See Figure 1)
Note: The 'Arrow' sticker indicates
the front of Base (L).
Figure 1
Figure 2
STEP 2
Attach Back Stretcher (E2) to Side Panel (B) with Head Cap Bolt (short). (See Figure 2)
Attach Back Pieces (F) and (G) to Back Stretcher (E2), then slide Back Panels (H) into place.
Attach Back Stretcher (E1) and Front Pieces (I) and (J) to unit with Head Cap Bolts (short).

Assembly Instructions 2/6

Head Cap Bolt (short)
B
H
E2
Wood Screw for Caster
Non-Locking Caster
'Arrow' sticker at front
Locking Caster
E1
G
F
H
H
L
I
J
G
H
