VISIX SOLUTIONS | VISIX VX-FR-01 Facial Recognition Camera – Hardware Installation Manual
Camera Description
See below for descriptions of the different camera components.
6
9
8
Number
Description
Camera Base Cover / Mounting
1
Plate
2
Camera Base
3
Safety Wire
4
Ethernet (RJ-45)
5
36VDC Power Supply
Wiring Harness (Audio In, Audio
6
Out, RS-485, Alarm Input, Alarm
Outputx2. GNDx3)
7
Camera Body
8
Lens
LED Indicators (Power, Link,
9
Status)
10
Cable routing hole cap
12000 Pecos Street, Suite 290, Westminster, CO 80234 | www.3xlogic.com | (877) 3XLOGIC
10
3
2
5
4
7
Camera Overview
Figure 1-2
1
8
