Installation
2
2
Position
1
2
3
Illustration 2.3 Assembly of the Adapter Flange to the OneGearDrive
6
®
VLT
OneGearDrive ExtensionBox™
1
3
Quantity
Item
1
Adapter
6
Washer
6
Adapter screw
Danfoss A/S © 02/2015 All rights reserved.
2
Comments
–
DIN 125, A10.5
DIN 912, M10 x 30, tightening torque:
20 Nm
MI75A102
