Installation
Assemble the torque arm as shown in Illustration 2.2.
2 2
2
1
8 4
Position Quantity
1 1
2 6
3 1
4 2
5 1
6 1
7 –
8 1
Illustration 2.2 Assembly View of the ExtensionBox with
Torque Arm

2.2.2 ExtensionBox

1. Grease the conveyor shaft.
2. Mount the ExtensionBox to the conveyor shaft
and fix it with the delivered retaining ring and
disc.
NOTICE
The screw [3] is not supplied and depends on the
conveyor shaft length. Refer to the chapter Assembly Kit
®
in the VLT OneGearDrive Operating Instructions for
further information.
3. Assemble the ExtensionBox in 30° steps (see
chapter 2.2.3 VLT
4. Close the hollow shafts with the cover (see
Illustration 2.4).
4
®
VLT
3
4
5
6
5
7
Item Comments
Torque arm –
Torque arm screw DIN 6921, M12 x
30, tightening
torque: 35 Nm
Screw ISO 4017, M12 x
90
Washer DIN 9021, A13
Damper –
Washer ISO 7090, M30
Customer support –
frame
Hexagon nut DIN 985, M12,
tightening torque:
43 Nm
®
OneGearDrive).
