Specifications

Product type
Model
Video system
Display method
LCD panel
Lens
Projection lamp
Component input/output
signal (INPUT1)
Horizontal resolution
Computer RGB input/output
signal (INPUT 1)
S-video input signal
(INPUT 2)
Video input signal
(INPUT 3)
Computer control signal (RS-232C)
Pixel clock
Vertical frequency
Horizontal frequency
Audio input signal
Audio output
Speaker system
Rated voltage
Input current
Rated frequency
Power consumption
Power consumption (standby)
Heat dissipation
Operating temperature
Storage temperature
Cabinet
I/R carrier frequency
Dimensions (approx.)
Weight (approx.)
Supplied accessories
Replacement parts
As a part of policy of continuous improvement, SHARP reserves the right to make design
and specification changes for product improvement without prior notice. The performance
specification figures indicated are nominal values of production units. There may be
some deviations from these values in individual units.
-74
LCD Projector
PG-B10S
NTSC3.58/NTSC4.43/PAL/PAL-M/PAL-N/PAL-60/SECAM/
DTV480I/DTV480P/DTV540P/DTV580I/DTV580P/DTV720P/DTV1035I/DTV1080I/
DTV1080I-50
LCD panel 3, RGB optical shutter method
Panel size: 0.55" (14.0 mm) (8.5 [H]
No. of dots: 480,000 dots (800 [H]
1–1.25 zoom lens, F1.6–1.9, f = 16.8–20.9 mm
130 W AC lamp
15-pin mini D-sub connector
Y: 1.0 Vp-p, sync negative, 75
P : 0.7 Vp-p, 75 terminated
B
P : 0.7 Vp-p, 75 terminated
R
520 TV lines (DTV720P)
15-pin mini D-sub connector
RGB separate/sync on green type analog input: 0–0.7 Vp-p, positive, 75
HORIZONTAL SYNC. SIGNAL: TTL level (positive/negative)
VERTICAL SYNC. SIGNAL: Same as above
4-pin mini DIN connector
Y (luminance signal): 1.0 Vp-p, sync negative, 75
C (chrominance signal): Burst 0.286 Vp-p, 75
RCA connector: VIDEO, composite video, 1.0 Vp-p, sync negative, 75
terminated
9-pin mini DIN connector
12–108 MHz
43–85 Hz
15–70 kHz
ø3.5 mm minijack: AUDIO, 0.5 Vrms, more than 22 k
1.0 W (monaural)
2.8 cm round 1
AC 100–240 V
1.9 A
50/60 Hz
185 W (Standard mode)/170 W (Eco mode) with AC 100 V
175 W (Standard mode)/160 W (Eco mode) with AC 240 V
4 W (AC 100 V) – 6 W (AC 240 V)
695 BTU/hour (Standard mode)/640 BTU/hour (Eco mode) with AC 100 V
660 BTU/hour (Standard mode)/600 BTU/hour (Eco mode) with AC 240 V
41°F to 95°F (+5°C to +35°C)
–4°F to 140°F (–20°C to +60°C)
Plastic
38 kHz
11 / " 3 / " 8 / " (294 (W)
37 5 3
64 8 4
11 / " 4 / " 9 / " (294.5 (W)
39 11 11
64 64 32
and projecting parts)
6.0 lbs. (2.7 kg)
Remote control, Two R-6 batteries, Power cord for U.S., Canada etc. (6', 1.8 m), Power cord
for Europe, except U.K. (6', 1.8 m), Power cord for U.K., Hong Kong and Singapore (6', 1.8
m), Power cord for Australia, New Zealand and Oceania (6', 1.8 m), RGB cable (9'10",
3.0 m), Carrying case, Lens cap (attached), Extra air filter, Lens shipping block (attached),
Projector manual and technical reference CD-ROM, "QUICK GUIDE" label, Operation manual
Lamp unit (Lamp/cage module) (BQC-PGB10S//1), Remote control (RRMCGA187WJSA),
Two R-6 batteries ("AA" size, UM/SUM-3, HP-7, or similar), Power cord for U.S., Canada etc.
(QACCDA016WJPZ), Power cord for Europe, except U.K. (QACCVA006WJPZ), Power cord
for U.K., Hong Kong and Singapore (QACCBA015WJPZ), Power cord for Australia, New
Zealand and Oceania (QACCLA005WJPZ), RGB cable (QCNWGA012WJPZ), Carrying case
(GCASNA009WJSA), Lens cap (CCAPHA004WJ01), Air filter (PFILDA010WJZZ), Lens ship-
ping block (SPAKXA333WJZZ), Projector manual and technical reference CD-ROM
(UDSKAA039WJZZ), "QUICK GUIDE" label (TLABZA439WJZZ), Operation manual (TINS-
A917WJZZ)
