Indicators

Filling level indicator (6)
A riser is installed on the front side of the lubri-
cant reserve container from which the filling le-
vel of the lubricant reserve container can be
read directly.
Pressure indicator
The pressure gauge (8) installed on the middle
block displays the inner pressure of the lubri-
cant reserve container.
Figure B - 1. Design of the L
UBRI
(schematic drawing, subject to technical al-
terations)
1 Compressed air connection
2 Main air valve
3 Atomizer air valve
4 Lubricant control valve
5 Pressure reducing valve
6 Filling level indicator
7 Lubricant inlet
8 Pressure gauge
9 Lubricant outlet
10 Control block
11 Solenoid valves
12 Manual actuation
13 Middle block
Filling level indicator (8)

Connections

Compressed air connection (1)
The minimum-quantity lubrication system
®
L L Vario has an NG8 coupling socket
UBRI EAN
for hoses with an inner diameter of 7-8 mm for
connection to the compressed air supply.
Electrical connection
The electrical connection is made via a terminal
box according to DIN 43650-C.
®
