Feature Identification - Snap-On SOLUS Edge Quick Start Manual

Item
Battery Status Indicator LED
• Green - battery is fully charged
1
• Red - battery is charging
• Amber - indicates there is a battery issue (correct before operating)
2 DC Power Supply Jack - AC/DC power supply connection
Mini USB Jack - USB cable connection used to transfer saved data files
3
to a personal computer
Micro secure digital (uSD) Card - Contains operating system
programming. IMPORTANT The uSD card must be installed to
4
operate the diagnostic tool. Do not remove the uSD card while the
diagnostic tool is turned on.
Data Cable Connector - Data cable connection used to connect the
5
diagnostic tool to a vehicle data link connector
Touch Screen - User interface to make onscreen menu and control
6
selections
N/X or Cancel Button - Push type button used to exit a menu or
7
program, return to the previous screen, or provide a "no" answer
Y/ a or Accept Button - Push type button used to accept or confirm a
8 selection from a menu, advance to the next screen, or provide a "yes"
answer
Directional Button - Thumb pad rocker type buttons used to move the
9 highlight/focus on the screen up, down, left, and right, as indicated by the
arrows.
Shortcut Button - Push type programmable button used to perform a
10
variety of routine tasks.
Power (On/Off) Button - Push type button used to turn the diagnostic
11
tool on and off. For emergency shutdown, press and hold for 5 seconds.
12 Battery Pack
13 Battery Pack Cover
14 Battery Pack Cover Screws (2)
15 Built-in Stand (shown closed)
Description
2

Feature Identification
