Atdec AF-AT-NBC Installation Manual page 2

1. Desk overview
The desk clamp bracket
can be repositioned to
suit different mounting
surface thicknesses.
2. How to reconfigure desk clamp
2.1 Remove screws
(M8 x 16mm Countersunk screw)
3. Post mount configuration
3.1 Attach clamp to post
M8 x 30mm
Countersunk
screw Tighten
firmly
5. Installing bolt through
5.1 Attach plate to post
Align rear hole with
hole on desk
M8x60mm
Screw
5mm
Allen key
1.1 Default
MIN THICKNESS - 0mm (0")
MAX THICKNESS - 39mm (1.5")
2.2 Remove clamp plate
3.2 Place in desired location
6. Install VESA monitor head
6.1 Install VESA monitor head as shown.
Bolt
through
plate
1.2 Inverted
2.3 Invert bracket 2.4 Replace clamp plate
3.3 Screw pressure plates
in and tighten firmly.
Pressure
Plate
M10 Desk
Clamp Screw
5mm Allen
Key
MIN THICKNESS - 35mm (1.4")
MAX THICKNESS - 76mm (3")
2.5 Reattach bracket
4. Bolt through
Drill 9mm hole in desired post
position on work surface.
9mm
(3/8")
Screen
VESA monitor
head
M4x10/12/16mm
Phillips head
mounting screws
Optional Spacers
(may be required
100mm
for recessed and
uneven surfaces)
AF-AT-NBC Page 2 of 4
100mm
