Back of Unit
MAN - Pyrolytic Oven - REV: Original | C. System Overview
Figure C.2: Pyrolytic Oven (Rear View)
1. Draft Inducer
2. Oxidizer Chamber
3. Oven Chamber
4. Electrical Control Box
5. Air Intake Filter
6. Ethernet Port
7. Draft Inducer Power Outlet
8. Power Cord
