- Page 1 Ultraviolet Disinfection Systems MODELS: GDS-7 GDS-15 Installation, Operation and Maintenance Manual CAUTION: Read and Follow all safety rules and operating instructions before first use of product. Dealer Info:...
- Page 2 GDS Series ©2016...
-
Page 3: Table Of Contents
....................10 Maintenance: ........................12 Unit Parts Breakdown: ....................13 Circuit Board Layout: ...................... 15 Wiring Diagram: ........................ 16 Troubleshooting: ......................17 Sterile Water Sample Procedures: ................18 Specifications: ........................19 Warranty: ..........................20 GDS ©2019 • www.aquat.com GDS Series ©2016... -
Page 4: General Safety Instructions
Watts than the disinfection system is rated for may cause over heating. Care should be taken to arrange the cord so that it will not be tripped over or accidentally pulled from the outlet. GDS ©2019 • www.aquat.com GDS Series ©2016... -
Page 5: Function / Description
Description The GDS series has an unique design with an ultraviolet germicidal lamp housed within a single quartz sleeve surrounded by a stainless steel pressure chamber. The chamber is fabricated out of 304 Stainless Steel. -
Page 6: Installation
(EXCEPT through an external sight Port lens located on the outside of the unit). 3. U.V. disinfection units must always be properly grounded. The GDS series are always placed after the pressure tank and any other type of treatment devices (i.e. softeners, filters). -
Page 7: Installation Diagram
Installation Diagram Recommendation: Use a 20 micron prefilter to reduce turbidity and for easy sanitation. GDS ©2019 • www.aquat.com GDS Series ©2016... -
Page 8: Electronic Controls & Startup Procedures
“re”, continue holding until you see the number 12 and hear it beep. At this point release the button. The 1 year lamp timer has just been reset. (Fig 4) GDS ©2019 • www.aquat.com GDS Series ©2016... - Page 9 Sample Screen Shots Fig. 2 Fig. 1 Fig. 4 Fig. 3 GDS ©2019 • www.aquat.com GDS Series ©2016...
-
Page 10: Sanitation Procedures
Drilled Wells - 3 to 8 inch diameter - 1 cup per foot of water NOTE: A. Chlorine may break loose iron deposits, slime and organic material. This material will make the water discolored. The material broken loose may plug pump screens. Do not GDS ©2019 • www.aquat.com GDS Series ©2016... - Page 11 0 - 1.5 0 - 3.0 0 - 6.0 0 - 8.0 0 - 12.0 1-1/2 1 - 5.0 2-1/2 2 - 0 3 - 0 ---- 12 - 0 ---- 26 - 0 ---- GDS ©2019 • www.aquat.com GDS Series ©2016...
-
Page 12: Maintenance
ELECTRICAL: frequency time according to the water quality of the home or facility application. The GDS series are furnished with 6’ line cord that will plug into a 110V outlet. Electrical receptacles must be properly QUARTZ SLEEVE CLEANING PROCEDURES: grounded for safe operation. Improper grounding will void To clean the quartz sleeve, turn off the water flow to the any warranty. -
Page 13: Unit Parts Breakdown
SCALE: WEIGHT: SHEET 1 OF 1 DO NOT SCALE DRAWING TITLE NAME DATE GDS ©2019 • www.aquat.com GDS Series ©2016 DRAWN 2/4/16 GDS-7 CUSTOMER MA UNLESS OTHERWISE SPECIFIED: PROPRIETARY AND CONFIDENTIAL CHECKED DIMENSIONS ARE IN INCHES THE INFORMATION CONTAINED IN THIS... - Page 14 DO NOT SCALE DRAWING TITLE NAME DATE GDS-15 CUSTO DRAWN 2/2/16 GDS ©2019 • www.aquat.com GDS Series ©2016 UNLESS OTHERWISE SPECIFIED: PROPRIETARY AND CONFIDENTIAL CHECKED DIMENSIONS ARE IN INCHES THE INFORMATION CONTAINED IN THIS TOLERANCES: DRAWING IS THE SOLE PROPERTY OF SIZE DWG.
-
Page 15: Circuit Board Layout
Circuit Board Layout GDS Series ©2016 GDS ©2019 • www.aquat.com... -
Page 16: Wiring Diagram
Wiring Diagram ATS-281P CIRCUIT BOARD ATS1-421-GDS ATS-4000 BALLAST PLUG UV LAMP GDS ©2019 • www.aquat.com GDS Series ©2016... -
Page 17: Troubleshooting
Check output voltage Replace ballast Loose open-circuit wire Trace out and repair Leak at quartz nipple Defective or cracked o-ring Replace o-ring O-Ring not seated properly Replace o-ring Cracked Quartz Sleeve Replace Quartz Sleeve GDS ©2019 • www.aquat.com GDS Series ©2016... -
Page 18: Sterile Water Sample Procedures
Check with your local laboratory to assure proper sampling and submittal procedure. GDS ©2019 • www.aquat.com GDS Series ©2016... -
Page 19: Specifications
GDS-7/15 Specifications GDS ©2019 • www.aquat.com GDS Series ©2016... -
Page 20: Warranty
Warranty GDS ©2019 • www.aquat.com GDS Series ©2016...
