dji Remote Controller C2 User Manual page 3

1. Sport Mode Switch
2. Function Button
3. Control Sticks
4. Antennas
5. Power Button
6. Mobile Device Clamp
7. Power Port (Micro USB)
8. Flight Pause Button
9. RTH Button
10. Status LED
11. Battery Level LEDs
12. Gimbal Dial
13. Customizable Button
14. Record Button
15. Shutter Button
1. Checking Battery Level and Charging
Checking Battery Level
Press the Power Button once to check the current battery level. Press once, then again
and hold to turn on/off the remote controller.
Charging the Battery
It takes approximately 2 hours to fully charge the remote controller.
Micro USB Port
* Spark's remote controller is currently only compatible with Spark aircraft.
** The remote controller can reach its maximum transmission distance (FCC) in a wide open area
with no Electro-Magnetic interference and at an altitude of about 120 meters. Maximum flight time
was tested in windless conditions flying at a constant speed of 12.4 mph (20 kph). This value
should be taken for reference only.
9
10
8
9
2
7
8
12
14
12
14
Low
USB Charger Power Outlet 100~240V
4
11
1
5
3
10
4
11
1
5
2
3
6
7
6
13
15
13
15
High
3
