- Page 1 OPERATION & SAFETY MANUAL SUPO-647 REV D PUSH-AROUND AERIAL WORK PLATFORM HB-P4.5 HB-P5.0 SERIES 1...
- Page 2 NOTES If there is a question about application and/ or operation, contact: Custom Equipment, Inc. 2647 Hwy 175 Richfield, WI 53076 U.S.A. Tel: +1-262-644-1300 Fax: +1-262-644-1320 www.hybridlifts.com Operation & Safety Manual SUPO 647 HB-P4.5 / HB-P5.0 REV D...
- Page 3 FOREWORD The purpose of this Operations and Safety manual is to provide users with the instructions and operating procedures essential to properly and safely operate the Custom Equipment Hy-Brid Lift for its intended purpose, and to position personnel and their necessary tools and materials. DANGER THE OPERATION AND SAFETY MANUAL MUST BE READ AND UNDERSTOOD PRIOR TO OPERAT- ING THE MACHINE.
-
Page 4: Table Of Contents
CONTENTS SECTION 1 | PRODUCT DESCRIPTION6 1.1 | General ................................. 6 1.2 | Machine Specifications ..........................7 SECTION 2 | SAFETY ..........................8 2.1 | Safety Symbols ............................8 2.2 | General Rules and Precautions ......................8 2.3 | Safety Features ............................9 2.4 | Safety Controls ............................ - Page 5 INDEX OF FIGURES Figure 1: Emergency Lowering Valve .....................10 Figure 2: Maintenance Lock Pin Use ...................... 11 Figure 3: Maintenance Lock Pin Storage ....................11 Figure 4: Decal Locations .........................13 Figure 5: Tie-Down Points ........................15 Figure 6: Rear Brakes ..........................15 Figure 7: Base Controls ..........................16 Figure 8: Platform Controls ........................16 Figure 9: Master Power Switch ........................
-
Page 6: Section 1 | Product Description6
SECTION 1 | PRODUCT DESCRIPTION 1.1 | General Custom Equipment’s Hy-Brid Scissor Lift is an aerial work platform designed to be safe and reliable. The purpose of the machine is to elevate personnel, along with their necessary tools and materials. The machine is intended for indoor use (no wind load). -
Page 7: Machine Specifications
SECTION 1 | PRODUCT DESCRIPTION 1.3 | Machine Specifications HB-P4.5 Working Height (maximum) 14 ft 4.5 m Platform Height (maximum) 8 ft 2.5 m Stowed Height 68.6 in 1.74 m Ground Clearance 1.6 in 0.04 m Overall Width 27.6 in 0.70 m Overall Length 43 in... - Page 8 SECTION 1 | PRODUCT DESCRIPTION HB-P5.0 Working Height (maximum) 16.4 ft 4.95 m Platform Height (maximum) 9.6 ft 2.95 m Stowed Height 71.1 in 1.81 m Ground Clearance 1.6 in 0.04 m Overall Width 27.6 in 0.70 m Overall Length 43 in 1.09 m Platform...
-
Page 9: Section 2 | Safety
SECTION 2 | SAFETY 2.1 | Safety Symbols Warnings and instructions that have a direct impact on safety are identified with the following sig- nals: DANGER “DANGER” indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. FAILURE TO FOLLOW THIS WARNING WILL CAUSE DEATH OR PERSONAL INJURY. -
Page 10: Safety Features
SECTION 2 | SAFETY WARNING NEVER REACH BETWEEN SCISSORS LINKS OR PROP UP PLATFORM. CAUTION WHEELS EXTENDING BEYOND THE SIDES OF THE BASE MAY OCCUR IN TIGHT TURNING SITUATIONS. 2.3 | Safety Features • Puncture-proof wheels. • Guardrails—43.83 in height with 4 in kick plates •... -
Page 11: Maintenance Lock
SECTION 2 | SAFETY WARNING If platform should fail to lower, do not attempt to climb down the beam assembly. Serious inju- ry may result. Have an experienced operator use the emergency lowering procedure to safely lower the platform. Emergency Stop This lift is equipped with two emergency stop switches, one at the platform control and one at the base control, that when activated, will render the unit inoperable until reset. -
Page 12: Safety Guidelines
SECTION 2 | SAFETY 2.6 | Safety Guidelines • Only qualified operators may operate this unit. • All operators must read and understand the Operation and Safety Manual. They must understand all decals and warning labels on unit. • Do not work on platform if your physical condition is such that you feel dizzy or unsteady in any way. •... - Page 13 Operation & Safety Manual SUPO 647 HB-P4.5 / HB-P5.O REV D...
-
Page 14: Section 3 | Decals
SECTION 3 | DECALS Figure 4: Decal Locations 1.12 1.17 1.13 1.14 1.11 1.12 1.11 1.13 1.11 1.15 1.16 1.10 1.11 Operation & Safety Manual SUPO 647 HB-P4.5 / HB-P5.0 REV D... - Page 15 SECTION 3 | DECALS Item # Part # Decal Meaning or Designation QTY. 144-21-007- Decals, HB-P4.5 DE600E-10 DECAL, MANUAL BOX DE600E-14 DECAL, ML DE751 DECAL,E-DOWN DE601 DECAL,LOGO DE603-7 DECAL, MODEL #HB-P4.5 DE603-8 DECAL, MODEL #HB-P5.0 DE746 DECAL,LANYARD ATTACHMENT DE652 DECAL,WEBSITE DE679 DECAL,HYDR FLUID DE706...
-
Page 16: Section 4 | Transport, Handling & Storage
SECTION 4 | TRANSPORT, HANDLING & STORAGE 4.1 | Preliminary Unpacking Instructions and Dealer Inspection Maintenance locks must be engaged prior to inspecting or servicing the unit when the platform is elevated. Inspect machine for any possible damage during shipment; perform a pre-delivery inspection. -
Page 17: Section 5 | Operation
SECTION 5 | OPERATION 5.1 | Pre-start Inspection Before use each day or at the beginning of each shift, the machine shall be given a visual inspection and functional test. Repairs (if any) must be made prior to operating the machine, as it is critical to ensure safe operation of the machine. -
Page 18: Startup/Shut Down
SECTION 5 | OPERATION 5.3 | Startup/Shut Down Check that the work area is safe. It is not recommended to maneuver the unit on a slope greater than 5°. Check that master power switch is in “ON” position. Ensure that the key in the lower con- trol panel is in the “ON”... -
Page 19: Elevating And Lowering
SECTION 5 | OPERATION 5.4 | Elevating and Lowering Using Upper Platform Controls Make sure the platform controls are selected with the selector switch at the base controls. To raise or lower the platform, press the Elevate/Lower Enable Button. While holding down the Enable But- ton, rotate and hold the Elevate/Lower switch until the platform is in the desired position. -
Page 20: Section 6 | Daily Maintenance
SECTION 6 | DAILY MAINTENANCE DANGER Failure to perform inspections and preventative maintenance at recommended intervals may result in the unit being operated with a defect that may result in injury or death of the operator. Regular inspection and conscientious maintenance is important to efficient economical operation of this machine. -
Page 21: Figure 11:Battery Charger Led Display
SECTION 6 | MAINTENANCE Battery solution is at its proper strength when the battery is manufactured. Use distilled water and keep fluid up to proper level. When required, water should be added to battery after charging, unless water level is below the plates. Figure 11:Battery Charger LED Display Reading the Battery Displays BATTERY 1 STATUS... -
Page 22: Pre-Start Inspection Checklist
SECTION 6 | MAINTENANCE 6.2 | Pre-start Inspection Checklist WARNING This checklist must be used at the beginning of each shift or after every six to eight hours of use. Fail- ure to do so could affect the safety of the operator. MODEL NUMBER: SERIAL NUMBER: Keep inspection records up-to-date. - Page 23 NOTES If there is a question about application and/ or operation, contact: Custom Equipment, Inc. 2647 Hwy 175 Richfield, WI 53076 U.S.A. Tel: +1-262-644-1300 Fax: +1-262-644-1320 www.hybridlifts.com Operation & Safety Manual SUPO 647 HB-P4.5 / HB-P5.O REV D...
- Page 24 © 2015 Custom Equipment, Inc. 2647 Highway 175 Richfield, WI 53076 U.S.A. Tel. +1-262-644-1300 Fax: +1-262-644-1320 www.hybridlifts.com service@customequipmentlifts.com “Hy-Brid Lifts” is a trademark of Custom Equipment, Inc. These machines comply with specified EN:280 requirements Revision Date: December 2015 Printed in the U.S.A.
