QUICK-START GUIDE
LRX LANDROLLERS
for
* Refer to operators manual for complete safety and operation info.
A
Connect Hydraulics
B
Opening into Field Position
1) Drive the LRX Landroller onto an area of level ground
large enough to open the wings. Ensure the Landroller is
positioned straight behind the tractor.
2) Remove the four Red Transport Bars from the End Wheel
& Center Wheel cylinders. Place the transport bars onto
the frame mounted storage brackets and secure with the
lock-pins.
Note: You may need to activate (extend) the
hydraulic cylinders slightly to allow easier
removal of the cylinder Transport Bars.
3) Activate the End Wheel
Cylinders
1
to completely
raise the end wheels and
lower the ends of the
drums to the ground.
4) Extend the Power-fold Cylinders
wings. Ensure the swing-arm shafts properly latch into
place.
4
IMPORTANT:
5)
Retract the
POWER-FOLD
Cylinders
Remember to retract
the Power-fold
Cylinders
back into
2
the fully closed position
before use.
*
1
2
3
2
1
2
to fully open the
4
2
2
5
2
REMEMBER! You must complete Product
Registration to be eligible for Warranty.
LATCH & END WHEELS....
SWING ARM CIRCUIT..................
CTR WHEEL & FLOAT....
6) Retract the Center Frame Cylinders
frame wheels (lowering the center section to the ground).
7) Remove the Red
Transport Pin from the
float hitch and secure
it in storage position.
8) Open the Hydraulic
Ball Valve.
3
9) Retract the Hitch Cylinder
to place the Landroller into Float Position.
10) The LRX Landroller should now be in the proper position
for field use. Read manual for further information.
4
(Refer to operators manual for complete safety and operation info.)
2
• Check for missing, worn or damaged parts.
• Working points & pins
• Hydraulic Connections & Hoses
• Hubs & Spindles
WARRANTY
Latch & End Wheel Cylinders
Power-fold Cylinders
Hitch & Center Wheel Cylinders
3
3
6
3
3
Maintenance
(Check Machine Daily)
to raise the center
3
6
8
9
7
143376 v1.1
