TOOLS REQUIRED
The Mini Switch requires only a screwdriver to fi nish assembly:
❍ #2 Phillips screw driver
KIT INSPECTION
Before starting to build, take an inventory of this kit to make
sure it is complete, and inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not of
acceptable quality, or if you need assistance with assembly,
contact Product Support. When reporting defective or
missing parts, use the part names exactly as they are written
in the Kit Contents list on this page.
Hobbico Product Support
3002 N Apollo Drive Suite 1
Champaign, IL 61822
E-mail: airsupport@hobbico.com
ORDERING REPLACEMENT PARTS
Replacement parts for the Hobbico Mini Switch are available
using the order numbers in the Replacement Parts List
that follows. The fastest, most economical service can be
provided by your hobby dealer or mail-order company. Parts
may also be ordered directly from Hobby Services, but full
retail prices and shipping and handling charges will apply.
Illinois and Nevada residents will also be charged sales tax.
To locate a hobby dealer, visit the Hobbico web site at
fl yzoneplanes.com. Choose "Find a Dealer" at the top of the
page. Follow the instructions provided on the page to locate
a U.S., Canadian or International dealer.
Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
2
3
4
10
9
7
12
Ph: (217) 398-8970 ext. 5
Fax: (217) 398-7721
CONTENTS
1. Fuselage
2. Low-wing Canopy Hatch
3. Horizontal Stabilizer
4. High-wing Canopy Hatch
5. Propeller Assembly
6. 3S Smart Charger
7. Screws
8. Wing Joiner Tube
9. 3S 11.1V 1300mAh LiPo
10. AA Batteries
11. TTX404 Transmitter
11
12. Left & Right Wing Panels
NOTE: Transmitter, AA batteries, 3S 11.1V LiPo
battery and 3S Smart Charger are not included in
the Tx-R Mini Switch.
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa
number and expiration date for payment.
Mail parts orders
and payments by
personal check to:
Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment by credit card or
personal check only; no C.O.D.
If additional assistance is required for any reason contact
Product Support by e-mail at productsupport@hobbico.com,
or by telephone at (217) 398-8970.
Order No.
FLZA6355
FLZA6356
FLZA6357
FLZA6358
FLZA6359
FLZA6360
FLZA6362
FLZA6364
FLZA6366
FLZA6367
FLZA6368
FLZA6369
FLZA6365
FLZA6361
FLZA6363
FLZA6370
FLZA6371
4
Hobby Services
3002 N Apollo Drive, Suite 1
Champaign IL 61822
REPLACEMENT PARTS LIST
Description
Wing Set Left & Right w/Decals
Fuselage w/Decals
Stabilizer & Elevator w/Tail Wheel
High Wing Canopy
Low Wing Canopy
Aluminum Landing Gear Assembly
Motor Mount Assembly
Spinner w/Propeller Adapter
Carbon Fiber Wing Tube
Canopy Mounting Screw
Pushrod & Control Horn Set
Low Wing Fuselage Foam Plugs
Battery Hatch Cover
Brushless Motor 28-30-1100kV
20 Amp Electronic Speed Control
8g Micro Servo
8x6 Electric Propeller
®
®
or MasterCard
