JAPANESE DIVE BOMBER
AICHI D3A1 "VAL"
VQ No: VQA138 GREEN
VQ No: VQA138 GRAY
Instruction manual / Montageanleitung
SPECIFICATIONS
Wingspan:......................................1540mm
Length:...........................................1120mm
Electric Motor:.....................See next pager
Glow Engine:.................... .46 2-T / .70 4-T
RTF Weight: 3.5Kg (will vary with equipment
use)
Radio:....................6 Channel / 8-9 Servos
Function: Ailerons-Elevator-Rudder-Throttle
Flaps.
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen. Bei unsachgemässer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstätzung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
Radio control model / Flugmodel
ALL BALSA, PLYWOOD CONSTRUCTION AND ALMOST READY TO FLY
TECHNISCHE DATEN
Spannweite:...................................1540mm
Lange:............................................1120mm
Elektroantrieb.............(siehe nächste Seite)
Verbrennerantrieb:...............7.45cc - 11.5cc
Fluggewicht:.......................................3.5Kg
Fernsteuerung..........6 Kanal / 8-9 Servos

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AICHI D3A1 VAL VQA138 GREEN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VQ AICHI D3A1 VAL VQA138 GREEN

  • Page 1 Radio control model / Flugmodel JAPANESE DIVE BOMBER AICHI D3A1 “VAL” VQ No: VQA138 GREEN VQ No: VQA138 GRAY ALL BALSA, PLYWOOD CONSTRUCTION AND ALMOST READY TO FLY Instruction manual / Montageanleitung TECHNISCHE DATEN SPECIFICATIONS Wingspan:........1540mm Spannweite:........1540mm Length:...........1120mm Lange:..........1120mm Electric Motor:.....See next pager Elektroantrieb.....(siehe nächste Seite)
  • Page 2 REQUIRED FOR OPERATION (Purchase separately) 10.5x6 for .40 - 2 cycle engine 11x6 for .46 - 2 cycle engine Flap: “Y” x2 pcs Aileron: 50cmx2 pcs 12x6 for .60 - 4 cycle engine 12x7 for .70 - 4 cycle engine Aileron: “Y”x1pcs Flap: 30cmx2 pcs 13x7 - 13x8 for electric motor...
  • Page 3: Engine Mount

    1- ENGINE MOUNT Attach the engine mount beams onto the fire-wall so the distance between of two engine mount beams is “A”,and B=B’ as show. Secure the engine mount beams onto the fire-wall with litter CA glue (1B) ! Align the mark on both engine mount Push left (or right) the magnetic fuel tank hatch beams with the mark on the fuselage and full it out of the fuselage.
  • Page 4 2- ENGINE ! Engine thrust on balk head is already adjust at factory C=122-124mm 122-124mm FUSELAGE SIDE-VIEW 3x25mm screw ..4 Washer Position the engine to the engine mounts so the distance from the prop hub ..4 to the fire-wall is 122 - 124mm. Mark the engine mounting plate where the four holes are to be drilled (2A) Reposition the engine on the engine mount beams, aligning it with the holes.
  • Page 5: Electric Motor

    3- ELECTRIC MOTOR Using a aluminum motor mounting plate as a template, mark the plywood motor mounting plate where the four holes are to be drilled. ! Align the mark on wooden motor Remove the aluminum motor mounting mounting plate with the mark on the fire-wall.
  • Page 6: Wheel Pant

    4- WHEEL PANT Slide the wheel pant mount onto the landing gear Secure the wheel pant mount in place using the 3mm screw set. Slide the landing gear with the wheel pant into the fiber glass wheel pant and secure it in place using the two clothespin and litter thin CA glue as shown (4B).
  • Page 7 5- WHEEL PANT continued Nylon gear strap ...4 3x10mm self tapping screw ....8...
  • Page 8 6- WHEEL PANT continued 2x6mm self tapping screw .....8 7- SERVO & CONTROL HORN Cut away only the covering Cut away only Cut away only the covering the covering Plastic control horn ..2 set...
  • Page 9 8- LINKAGES Secure the plastic control horn in place using the thin CA glue. Push the wooden dowel to the hole on the rib as show Ensure that the dowel is rectangular with the rib. Flap push-rod Secure it in place using the thin CA glue. Thin CA 2 mm Flap servo...
  • Page 10: Joining The Wing

    10- OUTER WING: LINKAGES Aileron push-rod Flap push-rod 2X175mm 1.2x120mm 2 mm 2 mm Thin CA Aileron servo Flap servo Steel clevis Plastic control horn ..2 ....2 set Aileron push rod 2x175mm ..2 Flap push rod 1.2x120mm ....2 Plastic control horn 2x30mm screw ....2 set ....4...
  • Page 11 12- JOINING THE WING continued 30 min. Epoxy Carefully slide the wing halves together, ensuring that they are accurately aligned. Firmly press the two halves together, allowing the excess epoxy to run out. Using a paper towel, clean off the excess epoxy. NOTE: Please do not clean off the excess epoxy on the wing with strong solvent or pure alcohol to keep the colour of your model not fade.
  • Page 12: Horizontal Stabilizer

    13- HORIZONTAL STABILIZER Using a sharp hobby knife, carefully cut away the covering around of all slots for the horizontal stabilizer and vertical fin installation. Remove the left and right elevator out of the horizontal stabilizer. Push the horizontal stabilizer into the slot on the fuselage as show.
  • Page 13 14- HORIZONTAL STABILIZER & VERTICAL STABILIZER Apply thin CA glue into the slot where the fuselage meet the horizontal stabilizer. Apply CA glue both sides. (thin CA) B=B’ B’ Install the horizontal stabilizer onto the fuselage and adjust the alignment as described in steep 13A.
  • Page 14: Vertical Stabilizer

    15- VERTICAL STABILIZER Insert the vertical fin into the fuselage, precisely align the vertical stabilizer as described in step 14C. Apply the thin CA glue on the vertical stabilizer where it contacts the fuselage. Remove the vertical stabilizer from the fuselage. Using s sharp hobby knife, carefully cut away the ! Securely glue together.
  • Page 15: Control Horn

    16- CONTROL HORN STABILIZER Plastic control horn ....2 set Cut away only the covering Apply thin CA glue on the left and right of the hinge Apply a thin layer of petroleum jelly RUDDER RUDDER ! Securely glue together. If coming off during fly, you lose control of your air plane.
  • Page 16: Plastic Shield

    18- TAIL WHEEL continued Insert the tail wheel push-rod into the hole on the tail gear control horn as show (18A). Insert the tail wheel push-rod with the tail gear control horn connected into the fuselage (18B). Install the tail wheel control horn in place (18C). Instal the tail wheel gear in place (18D).
  • Page 17 20- SERVO & LINKAGES Throttle push-rod 1.2x500mm 2 mm Throttle servo In case of Glow engine using 2x120mm rod Steel clevis Tail gear push-rod 1.2x800mm ..3 3mm set Screw 2x950mm rod ..3 (2 x120mm) rod ....2 Rudder push-rod 2x950mm (1.2 x500mm) throttle rod ....1 Triple connector Triple connector...
  • Page 18 At curves stretch sticker and apply a little heat so that no ceases occur. Cut off the excess that is produced. AICHI DECAL SHEET 40X36 VQ MODELS...
  • Page 19: Control Surface

    23- INSTALLATION THE WING 6x50mm nylon bolt ..2 24-BALANCE Note: Adjust the location of the battery pack to achieve this C.G location. (97 ~ 102mm) DO NOT try to fly an out-of balance model! Wing center section 25-CONTROL SURFACE (15mm) (10mm) (10mm) (15mm)
