FAq
q: N o image or audio output on display?
A: 1) Please check whether display on standby mode;
2) Please check whether display HDMI signal channel in accord
with HDMI input port;
3) Please check whether "LINK" LED on RX side keeps on, LED
flash means RX does not receive signal from TX;
4) Check the link light on the TX side is normally on, ON when
there is HDMI input signal, OFF when there is no HDMI signal.
q: Image unstable ?
A: 1) Please check the length button to adjust the length of the cable;
2) Please pull & plug CAT cable on corresponding port to reconnect.
q: O nly partial ports have output?
A: 1) Please check whether CAT cable or HDMI cable connected cor-
rectly;
2) Press the receiver or transmitter button to re-identify the signal;
3) Please pull & plug CAT cable on corresponding port to reconnect.

SpECIFICAtIOn

HDMI signal
Support resolutions
transmission distance
Ir Signal
EDID
Working temperature
power Supply
power consumption
Dimensions
Color
14
1x2 HDMI Extender Splitter
Specifications
HDMI1.3, compatible with HDCP1.2
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz, 1080p@50/60Hz,
Supports 20-60KHz IR devices
Support EDID setting function
0°C – 60°C
DC5V/2A
<15W
TX: 157.8 (L) x 62.0 (W) x 21.6 (H) mm
RX: 71.6 x 66.6 x 22.6 mm
Black
