COnnECtIOn InStrUCtIOn:

1) Connect the HDMI signal source device to the Transmitter HDMI
input port with HDMI cable.
2) Connect IR blaster to EXTENDER IR OUT.
3) Connect the Transmitter RJ45 port to HDMI EXTENDER RX's RJ45
input port by network cable.
4) Connect HDMI EXTENDER RX's HDMI output port to HDMI
display's HDMI input port by HDMI cable and set the HDMI
display's signal source to be HDMI port.
5) Supply the power (Power's signal light is red when there are signal
input then the power light is blue), the product will work.

EDID SEttInG

1) HDMI source device reads the EDID information of the transmitter
(TX) and then output the relative HDMI signal format.
2) There are 6 build-in EDID status, and others could be selected by
the EDID switch in the HDMI extender splitter (transmitter), the
detail Setting Information shown as below:
Switch Up: use the Arabic numeral "1" to represent
Switch DOWn: use the Arabic numeral "0" to represent
Switch status SW1 SW2 SW3
0 0 0
1 0 0
0 1 0
1 1 0
0 0 1
1 0 1
1 1 1
EDID mode
720P@50Hz 2.1CH
720P@50Hz 7.1CH
1080i@60Hz 2.1CH
1080i@60Hz 7.1CH
1080P@60Hz 2.1CH
1080P@60Hz 7.1CH
Default 720P@50Hz 2.1CH
