COMPONENT LOCATIONS

1
12
11
10
1. Engine exhaust
2. Radiator access panel
3. Central lift point
4. Fuel fill
5. Engine and battery access
6. Radiator drain port
7. Engine access
36949 B
3
2
13
9
Figure 2-3. Component Locations
MMG25I-35D-45I-55DF4 Operating Manual
6
8
8. Lug box panel access
9. Containment drain/fuel drain port
10. Receptacle panel
11. Emergency stop
12. Control access panel
13. Breaker panel access
