COMPONENT LOCATIONS

8
7
1. Radiator access panel
2. Battery and engine access
3. Customer convenience receptacles
4. Control panel access
37100 B
5
6
Figure 3 - Component Locations
MDG20IF4-MLG20IF4 Operating Manual
1
4
5. Ground stud
6. Tongue jack
7. Emergency stop switch
8. Fuel fill access
