General Description

This new generation barking dog alarm features realistic sounds and
voice operating status. Ferocious barking dogs, greetings or alarms are
available. Rex Plus
®
burglars, without the annoying problems of owning a real dog. With his
electronic radar eyes, Rex Plus
glass. Once the cord is plugged into any standard 120VAC outlet (for
indoor use only), he'll stay on duty around the clock. Portable operation is
available by installing the optional batteries. For temporary outdoor use,
battery operation only.
Operational Instructions
1. Plug in unit (Fig. 1).
2. Open lid. Adjust volume and sensitivity to
lowest level (fully counterclockwise). (Fig. 2)
3. Turn unit on. You will hear, "Warming up."
After 30 seconds, unit will say, "Armed." Red
LED will blink while warming up; solid when
ready.
4. Move switch to choose: Dog (
Greeting ( ) or Siren (
5. Press sound selection button to select sound
in each category. (Fig. 2)
6. Adjust volume and sensitivity, clockwise, to
desired level.
7. Point the front of the unit (wider face) towards
the area to be monitored. Note: The unit may
have reduced sensitivity at the back of the
unit. (Fig. 3)
15 minute mute (Red LED will blink)
• With lid open, tap the mute button.
• When lid is closed, tap raised grooves
on the lid to activate.
For temporary outdoor use, portable use or as
backup, install 6 "C" alkaline batteries.
After arming and no detection for 5 minutes,
the LED changes to a slow blink to extend
battery life. Note: When batteries are low
ED-55 will state "Please replace batteries,"
only at power up and when mute button is
pressed.
Operation Instruction Caution:
Place Rex Plus II at a height 3-5 feet from the
floor to obtain the widest range of detection.
The position and sensitivity may be adjusted
until optimal performance is reached. Setup
may take time and patience.
II is versatile and provides an excellent way to deter
II can "see" through doors, walls and
®
),
) (Fig. 2)
LOW
Volume
HIGH
LOW
VOLUME
(Shown min.
volume)
FRONT OF UNIT
(FACING AREA TO
BE MONITORED)
Fig. 1
HIGH
Fig. 2
LID
Fig. 3
FRONT OF
UNIT
SOUND SELECTION
BUTTON
LOW HIGH
SENSITIVITY
(Shown min.
sensitivity)
BACK OF UNIT
BACK
OF
UNIT
