Champion 100307 Operator's Manual page 32

100307 - 3500W DUAL FUEL GENERATOR
# Part Number
80 21.040007.00
81 21.040001.00
82 21.040008.00
83 24.040202.00
84 22.040009.00
85 22.040012.00
86 21.040021.00
87 1.97.1.06
88 1.6177.1.06
89 27.131017.01
90 27.131017.01.01
91 24.040201.00
92 23.040010.00
93 27.040005.00
94 21.020002.01
95 24.021000.00
96 23.020001.02
97 2.01.010
98 23.030006.00
99 27.091200.01
100 23.091003.21
101 23.091001.21
102 2.03.021.1
103 45.121000.00
104 1.5789.0840
105 27.030013.00
106 27.030013.01
107 2.08.121
108 1.5789.0620
109 24.040200.00
Description
Retainer, Exhaust Valve
Spring
Retainer, Intake Valve
Spring
Rotator, Exhaust Valve
Shaft, Rocker Arm
Rocker Arm, Intake Valve
Screw, Valve Adjustment
Nut M6 × 0.5, Lock
Washer Ø6
Flange Nut M6
Standard Main Jet
Altitude Main Jet
Retainer, Rocker Arm
Bolt, Rocker Arm
Push Rod
Gasket, Cylinder Head
Cover
Cover, Cylinder Head
Breather Tube 112 + 35
Stud Bolt M8 × 35
Plate, Coil
Cover, Air Cleaner
Element, Air Cleaner
Separator, Air Cleaner
Washer Ø6.4 × Ø13 × 1,
Black
Coil, Charging
Flange Bolt M8 × 40
Seal Strip, Crankcase
Cover, Long
Seal Strip, Crankcase
Cover, Short
Flange Bolt M10 × 65
Flange Bolt M6 × 20
Rocker Arm Assembly
Qty.
1
1
1
1
2
2
2
2
2
1
/
1
2
2
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
32
