Parameter Descriptions
5-30 Terminal 27 Digital Output
Option:
[181] Prev. Maintenance
[182] Deragging
[188] AHF Capacitor Connect
[189] External Fan Control
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve Control
[198] Drive Bypass
[199] Pipe Filling
5 5
[200] Full capacity
[201] Pump 1 running
[202] Pump 2 running
[203] Pump 3 running
[204] Pump 4 running
[205] Pump 5 running
[206] Pump 6 running
[207] Pump 7 running
[208] Pump 8 running
[209] Pump 9 running
5-50 Term. 29 Low Frequency
Range:
100 [0 - 110000
Hz Hz]
*
5-51 Term. 29 High Frequency
Range:
100 Hz [0 - 110000
*
Hz]
5-52 Term. 29 Low Ref./Feedb. Value
Range:
0.000 [-999999.999 -
*
999999.999 ]
24
®
VLT AQUA Drive MCO 101/MCO 102
Function:
Function:
Enter the low frequency limit
corresponding to the low motor shaft
speed (i.e. low reference value) in
5-52 Term. 29 Low Ref./Feedb. Value. Refer
to .
This parameter is available for FC 302
only.
Function:
Enter the high frequency limit
corresponding to the high motor shaft
speed (i.e. high reference value) in
5-53 Term. 29 High Ref./Feedb. Value.
This parameter is available for FC 302
only.
Function:
Enter the low reference value limit for
the motor shaft speed [RPM]. This is
also the lowest feedback value, see
also 5-57 Term. 33 Low Ref./Feedb.
Value. Set terminal 29 to digital input
(5-02 Terminal 29 Mode = [0] input
(default) and 5-13 Terminal 29 Digital
Input = applicable value).
MI38C402 - VLT
5-52 Term. 29 Low Ref./Feedb. Value
Range:
5-53 Term. 29 High Ref./Feedb. Value
Range:
100 [-999999.999 -
*
999999.999 ]
5-54 Pulse Filter Time Constant #29
Range:
100 [1 - 1000
ms ms]
*
5-60 Terminal 27 Pulse Output Variable
Option:
[0] No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[108] Torque +-160%
[109] Out frq 0-Fmax
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[116] Cascade Reference
5-62 Pulse Output Max Freq #27
Range:
5000 Hz [0 - 32000 Hz] Set the maximum frequency for
*

5.1.1 Cascade CTL Option, 27-**

Cascade Control Option parameter group.
®
is a registered Danfoss trademark
Function:
This parameter is available for FC 302
only.
Function:
Enter the high reference value
[RPM] for the motor shaft speed
and the high feedback value, see
also 5-58 Term. 33 High Ref./Feedb.
Value.
Function:
Enter the pulse filter time constant. The
pulse filter dampens oscillations of the
feedback signal, which is an advantage, if
there is a lot of noise in the system. A high
time constant value results in better
dampening but also increases the time
delay through the filter.
Function:
Select the desired display output for
terminal 27.
Function:
terminal 27, corresponding to the
output variable selected in
5-60 Terminal 27 Pulse Output Variable.
