Parameter Descriptions
3-17 Reference 3 Source
Option: Function:
Select the reference input to be used
for the third reference signal.
3-15 Reference 1 Source, 3-16 Reference
2 Source and 3-17 Reference 3 Source
define up to 3 different reference
signals. The sum of these reference
signals defines the actual reference.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[29] Analog Input X48/2
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
5-01 Terminal 27 Mode
Option: Function:
NOTICE
This parameter cannot be adjusted while the
motor is running.
[0] Input Defines terminal 27 as a digital input.
[1] Output Defines terminal 27 as a digital output.
5-13 Terminal 29 Digital Input
Option: Function:
Select the function from the available digital input
range and the additional options [60], [61], [63] and
[64]. Counters are used in Smart Logic Control
functions.This parameter is available for FC 302 only.
[14] Jog Functions are described under parameter group 5-1*
*
Digital Inputs
5-30 Terminal 27 Digital Output
Option:
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Stand-by / no warning
[5] Running
[6] Running / no warning
[8] Run on ref/no warn
[9] Alarm
®
VLT AQUA Drive MCO 101/MCO 102
5-30 Terminal 27 Digital Output
Option:
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[25]
[26]
[27]
[28]
[29]
[30]
[35]
[40]
[41]
[42]
[45]
[46]
[47]
[55]
[60]
[61]
[62]
[63]
[64]
[65]
[70]
[71]
[72]
[73]
[74]
[75]
[80]
[81]
[82]
[83]
Function:
[84]
[85]
[160]
[161]
[165]
[166]
[167]
[168]
[169]
[180]
®
MI38C402 - VLT is a registered Danfoss trademark
Alarm or warning
At torque limit
Out of current range
Below current, low
Above current, high
Out of speed range
Below speed, low
Above speed, high
Out of feedb. range
Below feedback, low
Above feedback, high
Thermal warning
Reverse
Bus OK
Torque limit & stop
Brake, no brake war
Brake ready, no fault
Brake fault (IGBT)
External Interlock
Out of ref range
Below reference, low
Above ref, high
Bus ctrl.
Bus ctrl, 1 if timeout
Bus ctrl, 0 if timeout
Pulse output
Comparator 0
Comparator 1
Comparator 2
Comparator 3
Comparator 4
Comparator 5
Logic rule 0
Logic rule 1
Logic rule 2
Logic rule 3
Logic rule 4
Logic rule 5
SL digital output A
SL digital output B
SL digital output C
SL digital output D
SL digital output E
SL digital output F
No alarm
Running reverse
Local ref active
Remote ref active
Start command act.
Hand mode
Auto mode
Clock Fault
