SimCom SIM7600V-H User Manual page 11

USB
Firmware upgrade USB
Physical characteristics
Temperature range
*Note: Module is able to make and receive voice calls, data calls, SMS and make
WCDMA/HSPA+/LTE traffic in -40℃ ~ +85℃. The performance will be reduced slightly from
the 3GPP specifications if the temperature is outside the normal operating temperature range
and still within the extreme operating temperature range.
SIM7600V-H_User Manual_V1.00
Can be used as the AT commands or data stream channel.
Support RTS/CTS hardware handshake
Multiplex ability according to GSM 07.10 Multiplexer Protocol.
USB 2.0 specification-compliant as a peripheral
Firmware upgrade over USB interface
USB 2.0 specification-compliant as a peripheral
Weight:5.5g
Size:30*30*2.9mm
Normal operation temperature: -30°C to +80°C
Extended operation temperature: -40°C to +85°C*
Storage temperature -45°C to +90°C
Smart Machine Smart Decision
11
2018-02-24
