Table 3: Pin Definitions
Pin No. Pin name
1 GND
3 PWRKEY
5 GND
7 SPI_MISO
9 SPI_CS
11 USB_VBUS
13 USB_DP
15 VDD_1V8
17 USIM_DATA
19 USIM_CLK
21 SD_CMD
23 SD_DATA1
25 SD_DATA3
27 SDIO_DATA1
29 SDIO_CMD
31 SDIO_DATA3
33 GPIO3
35 HSIC_STROBE
37 GND
39 VBAT
41 GND
43 GND
45 ISINK
47 ADC1
49 STATUS
51 NETLIGHT
53 USIM_DET
55 SCL
57 GND
59 AUX_ANT
61 GND
63 VBAT
65 GND
67 CTS
SIM7600V-H_User Manual_V1.00
Smart Machine Smart Decision
Pin No. Pin name
2 GND
4 RESET
6 SPI_CLK
8 SPI_MOSI
10 GND
12 USB_DN
14 GND
16 USB_ID
18 USIM_RST
20 USIM_VDD
22 SD_DATA0
24 SD_DATA2
26 SD_CLK
28 SDIO_DATA2
30 SDIO_DATA0
32 SDIO_CLK
34 GPIO6
36 HSIC_DATA
38 VBAT
40 GND
42 NC (RESERVED)
44 VDD_EXT
46 ADC2
48 SD_DET
50 GPIO43*
52 GPIO41
54 FLIGHTMODE
56 SDA
58 GND
60 GND
62 VBAT
64 GND
66 RTS
68 RXD
