FC 300 Extended Relay Card Operating In-
structions
[72] PID error inverse
[73] PID reset I-part
[74] PID enable
[80] PTC Card 1
5-20 Terminal X46/1 Digital Input
Option:
[0] * No operation
5-21 Terminal X46/3 Digital Input
Option:
[0] * No operation
5-22 Terminal X46/5 Digital Input
Option:
[0] * No operation
5-23 Terminal X46/7 Digital Input
Option:
[0] * No operation
5-24 Terminal X46/9 Digital Input
Option:
[0] * No operation
5-25 Terminal X46/11 Digital Input
Option:
[0] * No operation
5-26 Terminal X46/13 Digital Input
Option:
[0] * No operation
When enabled, it inverts the resulting error from the process PID controller. Available only if "Con-
figuration Mode" is set to "Surface Winder", "Extended PID Speed OL" or "Extended PID Speed CL".
When enabled, resets the I-part of the Process PID controller. Equivalent to par. 7-40
I-part Reset . Available only if "Configuration Mode" is set to "Surface Winder", "Extended PID Speed
OL" or "Extended PID Speed CL".
When enabled, enables the extended process PID controller. Equivalent to par. 7-50
Extended PID . Available only if "Configuration Mode" is set "Extended PID Speed OL" or "Extended
PID Speed CL".
All Digital Inputs can be set to PTC Card 1 [80]. However, only one Digital Input must be set to this
choice.
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
tions are described under 5-1* Digital Inputs
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
tions are described under 5-1* Digital Inputs
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
Digital Inputs
tions are described under 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
Digital Inputs
tions are described under 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
tions are described under 5-1* Digital Inputs
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
tions are described under 5-1* Digital Inputs
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
Digital Inputs
tions are described under 5-1*
