Primex Wireless
XR Transmitter
XR Transmitter with Attached Antenna
Operations Manual
Document number:
ECN:
Revision Date:
1014.200
2.00
July 13, 2006
N3211 County Road H
Lake Geneva 53147

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR and is the answer not in the manual?

Questions and answers

Related Manuals for Primex XR

Summary of Contents for Primex XR

  • Page 1 Primex Wireless XR Transmitter XR Transmitter with Attached Antenna Operations Manual Document number: 1014.200 ECN: 2.00 Revision Date: July 13, 2006 N3211 County Road H Lake Geneva 53147...

  • Page 2: Table Of Contents

    ....................... 6 ARDWARE EFINITIONS 2.1.1 Back Panel Picture ........................6 2.1.2 Front Panel Picture ........................6 2.1.3 Overall Picture of the XR Transmitter..................6 2.1.4 Connector and Peripheral Definition................... 7 2.2 XR T ........................9 RANSMITTER 2.2.1 General Set Up Considerations ....................9 2.2.2 Hardware Set up...........................

  • Page 3: Introduction

    1.2.5 FCC License Requirements Operation of the XR transmitter requires an FCC operating license which must be applied for by the operator of the equipment. The XR models with attached whip antennae require a mobile license. Prior to operating the XR transmitter, an application must be filed with the FCC and a license granted from the FCC.

  • Page 4: Canada Ic Information And Requirements

    The usage of other power supplies is not approved and may affect the transmitter’s operation. The transmitter is designed for indoor use in a non-condensing, non-wet area. Operating the XR transmitter outdoors is an electrical hazard and may damage the transmitter and devices attached to the transmitter, and may void the warranty.

  • Page 5: General Overview

    RF – Radio Frequency • RX – Receive. • TX – Transmit or Transmitter (referring to our XR Transmitter) • UTC – Universal Coordinated Time, a.k.a. Coordinated Universal Time. Replaces the previous GMT standard. • WTG = Wireless Tone Generator...

  • Page 6: Xr Transmitter Product Operation

    2.1.3 Overall Picture of the XR Transmitter This a picture of the transmitter which shows the whip antenna attached to the NMO mount on the case top. Figure 4 – Overall Picture of XR Transmitter Showing the NMO Antenna Mounted Confidential Document...

  • Page 7: Connector And Peripheral Definition

    New transmitter Document: 1014.100 ECN: 1.10 2.1.4 Connector and Peripheral Definition Figure 5 - External Hardware Connections RF Board based Connector Description Connector type GPS IN Input from GPS receiver 7 pin mini-DIN NETWORK LAN Network connection, connects to Lantronix RJ45 serial port internally.
  • Page 8 New transmitter Document: 1014.100 ECN: 1.10 Figure 6 - Control Inputs Input Description Interface type Channel Select RF Operating Frequency X2 Rotary BCD Number Switches with shaft and knob Time Zone Needed to adjust for 24 time zone offsets Rotary Hex switch with screwdriver activated knob GPS/NTP...

  • Page 9: Xr Transmitter Set Up

    2.2.1 General Set Up Considerations The XR transmitter should be located in an area that maximizes the propagation of the signal to the largest area in the facility. The FCC license needs to be applied for and granted before the equipment can be set up and operated. The channel switch setting on the back of the transmitter must match the channel authorized by the license.
  • Page 10 Document: 1014.100 ECN: 1.10 e. If this transmitter is to be locally connected to an XR server, the CAT 5 cable from the server must be plugged into the NETWORK LAN CONNECTOR on the back of the transmitter. Make sure the NTP/GPS switch on the back of the XR transmitter is in the LAN position.

  • Page 11: Xr Transmitter Operation

    • If the XR transmitter has not recently been powered up, the time will start at 00:00:00 if in the 24 hour mode are at 12:00:00 am if in 12 hour mode and there will be no parentheses to the right of the GPS tower symbol which indicate that the transmitter is synchronized and the green LED will be off indicating that the transmitter is not broadcasting.

  • Page 12: Detailed Panel And Menu Operation

    New transmitter Document: 1014.100 ECN: 1.10 • If an error condition has occurred (the Red LED is flashing) the bottom line will have a scrolling error message instructing the operator to look at the diagnostic menus or to call Technical Support. 2.3.3 Detailed Panel and Menu Operation Normal Display –...
  • Page 13 New transmitter Document: 1014.100 ECN: 1.10 DST Switch (same as the ST/DST switch) 12/24 Hour Format (same as the 24H/12H switch) GMT Offset (same as the UTC+/UTC- switch) LAN/LOCAL NTP/GPS Diagnostics Firmware Rev Time Since Last GPS Hardware Revi GPS/Repeater Last Rptr Update Serial Number MAC Address...

  • Page 14: Product Specifications

    New transmitter Document: 1014.100 ECN: 1.10 3. P RODUCT PECIFICATIONS Parameter Specification Frequency Range 72.02 to 75.98 MHz Transmission Range 1 mile open field Radio Technology Narrowband FM Modulation Number of Channels 50 Mobile under Part 90.35 48 Fixed under Part 90.257(a) Channel Bandwidth 20KHz Transmission Mode...
