- Page 1 XR T YNCHORNIZATION 14000 S ERIES ATELLITE RANSMITTER & U NSTALLATION UIDE Doc Part No.: 14000M 082713...
- Page 2 Lake Geneva WI 53147 Unit #4 Halifax, West Yorkshire HX3 5AX Newmarket, ON L3Y 8V6 Email info@primexinc.com info@primexwireless.ca info@primexwireless.co.uk www.primexwireless.com www.primexwireless.ca primexwireless.co.uk Telephone (800) 537-0464 (800) 330-1459 0800-3896996 (262) 248-0061 (905) 952-0134 01422-349462 Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide...
-
Page 3: Table Of Contents
Setup the Transmitter Setup Receiver Switch Internal Dip Switch Configuration Signal Indicator Install Receiver Switch Confirm Reception Last Time Update Special Circumstances Setup Multiple Transmitters Within the Same Facility Support Warranty Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide... -
Page 4: Regulatory Compliance
FCC licenses must be renewed every 10 years and the IC licenses must be renewed annually. As a service, Primex Wireless will file the license application if the end-user desires it. An end-user that does not want Primex Wireless to file for the original site license will be required to complete a waiver form, file the required application, and receive a valid license from the FCC/IC prior to use.If you have any questions or need any assistance,... -
Page 5: Important Safety Instructions
Do not open the transmitter to alter the internal elements in any way. This will void the warranty and could lead to unsafe conditions, malfunction, and violations of FCC/IC regulations. Primex Wireless disclaims any liability or responsibility for the results of improper or unsafe installation practices. Primex Wireless... -
Page 6: System Specifications
This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. Transmitter Display Specifications The transmitter has a lighted front display that shows important information. Figure 1: 14000 Series Transmitter Display Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide... - Page 7 0.75 lb (.34kg) Input: 120 VAC, 50/60 Hz, 0.4 Amp Power Supply Output: 9 VDC, 0.25 Amp, 6' (1.83m) cord Operating Range -32° - 158° F (-36° - 70° C) Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide...
-
Page 8: Installation And Configuration
NSTALLATION AND ONFIGURATION This section provides the procedures required to install and configure your 14000 Series Satellite Transmitter system and components. Verify Setup Primary Transmitter with GPS Receiver Installation of the Satellite Transmitter begins with setup of the primary transmitter with GPS receiver. -
Page 9: Setup The Transmitter
1. Set the switch preferences located on the back of the transmitter The transmitter continually checks the position of the switches. The switches select time zone, channel number, 12- or 24-hour display, and the observance of Daylight Saving Time. Figure 5: 14000 Transmitter - Back View Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide... - Page 10 Installation and Configuration Setup the Transmitter Table 4: 14000 Series Transmitter - Switch/Component Specifications Switch/Component Description Rotary Switch A (channel selection) Factory preset to the FM frequency on which the transmitter will broadcast. Warning: Do Not adjust this switch. It is only to be set to the frequency specified on the FCC/IC There are 16 available channels.
-
Page 11: Setup Receiver Switch
After entering changes, it is recommended to step through the menu options until the option donE is displayed to exit the menu mode; the menu will display donE. NOTE: Changes made in the Menu will be saved when the menu is exited. Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide... -
Page 12: Internal Dip Switch Configuration
Green LED will flash for 60 minutes when it has received a valid time update or Green LED will remain solid for 60 minutes if it has NOT received a valid time update. Yellow LED will continue to flash if the unit goes 48 hours without receiving a time update. Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide... -
Page 13: Install Receiver Switch
DO NOT hold the rubber antenna during testing, as this can affect the sensitivity of the receiver. Instead, hold the switch by the sides of the housing while locating the best mounting position. Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide... -
Page 14: Confirm Reception
1. Disconnect the receiver switch from the Satellitle Transmitter. 2. On the Receiver Switch remove the access cover and change dip switch #5 to the “ON” position, as shown in Figure 9 Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide... - Page 15 Special Circumstances Figure 9: Receiver Switch with Cover Removed Primex Wireless 14000 Series Satellite Transmitter Installation & User Guide...
-
Page 16: Setup Multiple Transmitters Within The Same Facility
2. The channel number of the Satellite Transmitter is preset to the channel number specified on the red label, located on the top of the box the transmitter was packaged in. Contact Primex Wireless Technical Support if you require assistance. -
Page 17: Support
Contact Technical Support Before contacting Primex Wireless Technical Support, make sure you have satisfied the system requirements that are listed in your product documentation. When you contact Technical Support, please have the following information available:... -
Page 18: Warranty
Primex Corporation warrants this product to be free from defects in materials and workmanship for a standard of one year from the date of purchase. Primex will at its sole option, repair or replace any components that fail in normal use. Such repairs or replacements will be made at no charge to the customer for replacement parts.
