- Page 1 XR T YNCHORNIZATION UK 1/2 & 5 W RANSMITTER XTERNAL NTENNA & U NSTALLATION UIDE Doc Part No.: XRK01E 06.13.16...
- Page 2 Legal Notice Copyright ©2016 Primex Wireless, Inc. All rights reserved. U.S. Patents 6,873,573; 7,352,657. Other Patents Pending. Printed in the USA. Information in this document is subject to change without notice. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical or otherwise, for any purpose, without the prior written permission of Primex Wireless.
-
Page 3: Table Of Contents
ONTENTS Important Safety Instructions Regulatory Compliance DECLARATION OF CONFORMITY XR Time Synchronization System Overview Architecture Time Synchronization Precision Timing 1 Watt Transmitter System Specifications System Components 1/2 Watt XR Transmitter Specifications GPS Receiver Specifications External Antenna - Ground Plane Omnidirectional Antenna Specifications... - Page 4 Clear Error Codes Troubleshooting XR Transmitter General Troubleshooting Green LED - XR Transmitter Yellow LED - XR Transmitter Red LED Troubleshooting - XR Transmitter Support Warranty Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide...
-
Page 5: Important Safety Instructions
Antenna systems should be inspected once a year by qualified personnel to verify proper installation, maintenance, and condition of equipment. Primex Wireless disclaims any liability or responsibility for the results of improper or unsafe installation practices. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 6: Regulatory Compliance
U.S.A. declare under our sole responsibility that the product The Primex Wireless Synchronized Time XR-68 Radio Transmitter and the 68XR5 Radio Transmitter to which this declaration relates, is in conformity with the following standards and/or other normative documents. ETS EN 300 113-1 EN 300 113-2... -
Page 7: Xr Time Synchronization System Overview
VERVIEW Architecture The XR Time Synchronization System has been designed with customization in mind. It provides a scalable solution that offers time synchronization services for a variety of devices and components. The system ranges from a a single transmitter, GPS Receiver, NTP time source, and a handful of clocks in a single building, to a campus wide deployment. -
Page 8: Watt Transmitter System Specifications
RANSMITTER YSTEM PECIFICATIONS This section provides the specifications of the XR Time Synchronization 1 Watt Transmitter. System Components 1 Watt Transmitter - External Antenna Model Transmitter Ground Plane Omnidirectional Antenna 100' (30.48 m) LMR 400 coaxial cable Gelwrap splice enclosure... -
Page 9: 1/2 Watt Xr Transmitter Specifications
This power reduction is to be by means of input power or gain reduction and not by an attenuator at the output of the device. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 10: Gps Receiver Specifications
3.5”W x 1.4”H x 4.5”D (8.89 cm x 3.56 cm x 11.43 cm) Mounting Bracket Included for rooftop or window installation. 0.75 lb. (.34 kg) Weight -32°- 158°F (-30° - 70°C) Operating Range Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 11: External Antenna - Ground Plane Omnidirectional Antenna Specifications
* Mechanical design is based on environmental conditions as stipulated in EIA-222-F (June 1996) and/or ETS 300 019-1-4 which include the static mechanical load imposed on an antenna by wind at maximum velocity. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 12: Install External Antenna - 1 Watt Transmitter
9. Connect the transmitter time source. 10. Configure the NTP time (optional). 11. Establish the transmitter settings and verify connections. 12. Verify the system is operational. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 13: Typical System Install Setup - 1 Watt Transmitter With External Antenna
Penetrating mount only: 5/8" concrete drill bit, 18” (45.7 cm) long 1/2” wrench 3/4' deep well socket with ratchet 10” (25.4 cm) adjustable wrench Phillips screwdriver Flat head screwdriver Lineman’s pliers Shears/scissors Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 14: Transmitter Installation Location Guidelines
NOTE: Prior to installation and to assure optimum performance of the system, it is recommended a Primex Wireless Application Engineer performs a site survey. The site survey includes an analysis and recommendation of the installation location of the system components and ground plan omnidirectional antenna. -
Page 15: Assemble Ground Plane Omnidirectional Antenna
9' (2.74 m). 4. Align the sections fastening holes and secure sections together using the supplied hex bolt and nuts. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 16: Mount The Antenna Mast
NOTE: Installation requires six 8" x 8" x 16" concrete blocks (not supplied). Kit Contents The kit is supplied with the following parts. If any of these items are missing, please contact Primex Wireless. Description Rigid galvanized conduit mast | 5’ by 1.25” (1.5 2 m x 3.17 Tripod leg | 27"(2.54 cm) each in length... - Page 17 Figure 3: Non-Penetrating Mount Illustration Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide...
-
Page 18: Install Penetrating Antenna Kit
5/8" (1.58 cm) diameter mounting hole is required and the maximum diameter of the pole or wall thickness is 14" (35.56 cm). Kit Contents The kit is supplied with the following parts. If any of these items are missing, please contact Primex Wireless. Description Rigid galvanized conduit section | 5’ by 1.25”... - Page 19 15. Next, route the antenna cable. For additional information, see "Route Antenna LMR 400 Coaxial Cable" located on page 23. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide...
-
Page 20: Install Antenna Pole Mount Kit
The center section of each clamp is welded to proved mechanical stability and all parts are hot-depped galvanized steel. Kit Contents The kit is supplied with the following parts. If any of these items are missing, please contact Primex Wireless. Description 5’... - Page 21 Figure 5: Pole Mount Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide...
-
Page 22: Ground The Antenna Mast
NOTE: Cut the 50’ wire off at the necessary length. The remainder of the wire will be used to ground the transmitter. 3. Connect the other end of the #6 gauge wire to a verified building/earth ground. Figure 6: Ground Clamp Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 23: Route Antenna Lmr 400 Coaxial Cable
4. Form and secure two 1’ diameter (305 mm) loops in the LMR 400 cable at the base of the mast for lightning protection. 5. Connect the LMR 400 cable to the antenna. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 24: Install Gps Receiver
Complete the steps below to install a GPS receiver. A GPS receiver is required if your system will use GPS as its time source. Mounting Kit Contents The GPS Receiver mounting kit is supplied with the following parts. If any of these items are missing, contact Primex Wireless. -
Page 25: Complete Final Antenna Mounting Requirements
The antenna must be snug and flat against the case. 2. Connect the time source to the transmitter. The system can be configured to either utilize GPS or NTP time. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 26: Configure Ntp Time (Optional)
The transmitter has the option to be configured to use NTP time. If the system will use NTP as its time source, complete the following configuration procedures. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... - Page 27 IP address is changed, the factory-default IP address will no longer work and you must use the new settings to access the transmitter configuration. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide...
-
Page 28: Configure Transmitter Network And Ntp Time Settings
Figure 9: Connect To Dialog Box 6. Leave both user name and password blank, click OK to log into the transmitter. The XPort Device Configuration Manager screen is displayed. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... - Page 29 7. Click Network. The Network Settings screen is displayed. Figure 11: Network Settings Screen 8. To change the factory default static IP address, use options in the Network Settings screen. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide...
-
Page 30: Set A Temporary Ip Address For The Transmitter Lan Interface
NOTE: The temporary IP address assigned using this procedure is only accessible as long as the transmitter is powered. If power is lost before the desired IP address is configured, you will need to repeat this procedure. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... - Page 31 IP address of the transmitter. If replies are received, you will be able to access the transmitter through the web interface. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide...
-
Page 32: Configure Transmitter Settings
Time Zone External Antenna models and 5 Watt and 30 Watt models: the time zone is present by factory. If your application requires adjustments to these settings, please contact Primex Wireless Technical Support for more information. Internal Antenna models: set the Time Zone dial to your system time zone using the dial Time Zone switch. -
Page 33: Verify System Is Operational
3. Verify the Channel Number is set correctly. 4. Verify the transmitter does not have any error codes. For additional information, see "Diagnostics Menu" located on page 38. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 34: Transmitter Operation
NOTE: In the event of a facility-wide power outage, upon power restoration, transmitters using scheduled transmission will broadcast continuously for 8 hours, synchronizing all the Primex Wireless products throughout your facility. Primex Wireless... -
Page 35: Transmitter Status - Front Lcd Panel
GPS Receiver and the transmitter. When the transmitter is receiving valid time data from the GPS receiver, the three parentheses symbol will sequence in a motion pattern. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 36: Led Status Indicator - Xr Transmitter
Yellow Warning LED: If flashing, the transmitter needs attention. Red Error LED: If flashing, the transmitter requires attention. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 37: Time Zone And Time Settings
Tech Support Info: displays support contact information Switch Settings Menu Setting Move the selection arrow so that it is pointing to Switch Settings then press the (right arrow) button once. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 38: Gps Setup Menu
Hardware Rev: displays the hardware revision number GPS/Repeater: displays if there is a GPS or a Repeater connected. If NTP is the time source, Repeater will be displayed. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 39: Identify Active Diagnostic Error Code
3. Use the down arrow button to scroll to the error, which is indicated by a preceding dot next to the error. 4. Press the right arrow button once. The display will show when the error was logged. Note the time and data of the error. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... - Page 40 NOTE: If the LEDs continue to flash, repeat procedure as there may be additional errors to be cleared. If same errors continue to be logged, contact Technical Support. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide...
-
Page 41: Troubleshooting Xr Transmitter
When certain types of electronic light ballasts become defective they may radiate broadband noise, which can interfere with wireless devices. While interference issues are unlikely with the Primex Wireless Clock System, high levels of noise present in the 72-76MHz range could potentially cause clocks which are located far from the transmitter and also within the close proximity of these ballasts to not receive a signal. - Page 42 If this does not correct the problem, either the power supply or the transmitter may be defective.Contact Primex Wireless Technical Support. Display lights up, but is blank or very faint. The transmitter may need to be replaced. Recommended action Contact Primex Wireless Technical Support.
-
Page 43: Green Led - Xr Transmitter
The transmitter did not get an initial time and is not broadcasting, or a software/hardware error is preventing full transmission output. Recommended action Contact Primex Wireless if yellow and red LEDs are off. Primex Wireless UK 1/2 and 5 Watt Transmitter - External Antenna Installation & User Guide... -
Page 44: Yellow Led - Xr Transmitter
2. Cycle power /Re-initialize the unit (unplug the transmitter, wait a few moments and then plug it back in) 3. Clear error from log. 4. If light and error message return, contact Primex Wireless. Mode: Transmitter Error Code: No GPS for 48 hours The the GPS connection symbol present. -
Page 45: Red Led Troubleshooting - Xr Transmitter
2. Power cycle/re-initialize the unit (unplug the transmitter, wait a few moments and then plug it back in). 3. Clear error from log. 4. If light and error message return, contact Primex Wireless What does it indicate if the Red LED is flashing - system with multiple transmitter(s) or repeater configuration? - Page 46 1. Power cycle/re-initialize the unit (unplug the transmitter, wait a few moments and then plug it back in). 2. Clear error from log. 3. If light and error message return, contact Primex Wireless. What does it indicate if the Red LED is flashing for an External Antenna transmitter model? Mode: Transmitter - External Antenna Model only VSWR Errors - There is a problem with either the external antenna or the antenna cabling.
-
Page 47: Support
When you contact Technical Support, please have the following information available: Customer ID Problem description Device hardware information Error messages Troubleshooting performed before contacting Primex Wireless Recent network changes (SNS products only) Technical Support (800) 404-8112 Telephone techsupport@primexinc.com... -
Page 48: Warranty
Primex Corporation warrants this product to be free from defects in materials and workmanship for a standard of one year from the date of purchase. Primex will at its sole option, repair or replace any components that fail in normal use. Such repairs or replacements will be made at no charge to the customer for replacement parts.
