- Page 1 XR T YNCHORNIZATION UK S ATELLITE RANSMITTER & U NSTALLATION UIDE Doc Part No.: XR006M 08.27.14...
- Page 2 Legal Notice Copyright ©2014 Primex Wireless, Inc. All rights reserved. U.S. Patents 6,873,573; 7,352,657. Other Patents Pending. Printed in the USA. Information in this document is subject to change without notice. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical or otherwise, for any purpose, without the prior written permission of Primex Wireless.
-
Page 3: Table Of Contents
Internal Dip Switch Configuration - Time and Channel Scan Settings Signal Indicator Install Receiver Switch Confirm Reception with Transmitter Verify Last Time Update Special Circumstances - BST Time not Observed Setup Multiple Transmitters Within the Same Facility Support Warranty Primex Wireless Satellite Installation & User Guide... -
Page 4: Important Safety Instructions
Do not open the transmitter to alter the internal elements in any way. This will void the warranty and could lead to unsafe conditions, malfunction, and violations of regulations. Primex Wireless disclaims any liability or responsibility for the results of improper or unsafe installation practices. Primex Wireless... -
Page 5: Regulatory Compliance
U.S.A. declare under our sole responsibility that the product The Primex Wireless Synchronized Time XR-68 Radio Transmitter and the 68XR5 Radio Transmitter to which this declaration relates, is in conformity with the following standards and/or other normative documents. ETS EN 300 113-1 EN 300 113-2... -
Page 6: Satellite Transmitter Specifications
12.5" (31.75 cm) L Antenna 0.75 lb (.34 kg) Weight Input: 230 VAC, 50/60 Hz Power Supply Output: 9 VDC, 1700 mA, 6' (1.83 cm) cord -32° - 158° F (-36° - 70° C) Operating Range Primex Wireless Satellite Installation & User Guide... -
Page 7: Configure And Install Satellite Transmitter
Typical Application Drawings CAUTION: Do not adjust the channel numbers on your transmitter. This figure is an example designed to demonstrate how a repeater switch chain works. Figure 1: Example of Horizontal Installation Primex Wireless Satellite Installation & User Guide... -
Page 8: Set Satellite Transmitter Preferences
Turn to 4 for Atlantic Time Zone Turn to 5 for Eastern Time Zone Turn to 6 for Central Time Zone Turn to 7 for Mountain Time Zone Turn to 8 for Pacific Time Zone Primex Wireless Satellite Installation & User Guide... -
Page 9: Setup Receiver Switch
If a value is changed while cycling through the menu, it will be saved and continue to cycle. While in test mode, it will remain in the selected mode until the menu button is pressed again to exit. Primex Wireless Satellite Installation & User Guide... -
Page 10: Internal Dip Switch Configuration - Time And Channel Scan Settings
12 hour format. displays the time in 24 hour format. RF Channel Scan disable the scan and only look on the selected enable the scan and channel for time/date/event info. look for a suitable channel. Primex Wireless Satellite Installation & User Guide... -
Page 11: Signal Indicator
Green LED will flash for 60 minutes when it has received a valid time update or Green LED will remain solid for 60 minutes if it has NOT received a valid time update. Yellow LED will continue to flash if the unit goes 48 hours without receiving a time update. Primex Wireless Satellite Installation & User Guide... -
Page 12: Install Receiver Switch
3. Connect the serial cable of the Receiver Switch into the GPS IN Socket on the back of the Satellite Transmitter. Figure 6: Satellite Transmitter - Back View 4. Power up the Satellite Transmitter. Primex Wireless Satellite Installation & User Guide... -
Page 13: Confirm Reception With Transmitter
Last Time Update (LTU) section. Special Circumstances - BST Time not Observed For geographic areas that do not observe British Summer Time (BST) set the transmitter's British Summer Time (BST) reciver switch bypass step below. Primex Wireless Satellite Installation & User Guide... - Page 14 1. Disconnect the receiver switch from the Satellite Transmitter. 2. On the Receiver Switch remove the access cover and change dip switch #5 to the “ON” position, as shown in Figure 7 Figure 7: Receiver Switch with Cover Removed Primex Wireless Satellite Installation & User Guide...
-
Page 15: Setup Multiple Transmitters Within The Same Facility
2. The channel number of the Satellite Transmitter is preset to the channel number specified on the red label located on the top of the box the transmitter was packaged in. Contact Primex Wireless Technical Support if you require assistance. -
Page 16: Support
Contact Technical Support Before contacting Primex Wireless Technical Support, make sure you have satisfied the system requirements that are listed in your product documentation. Also, you should be at the computer on which the problem occurred, in case it is necessary to replicate the problem. -
Page 17: Warranty
Primex Corporation warrants this product to be free from defects in materials and workmanship for a standard of one year from the date of purchase. Primex will at its sole option, repair or replace any components that fail in normal use. Such repairs or replacements will be made at no charge to the customer for replacement parts.
