TROUBLESHOOTING

RE-CALIBRATING THE DRONE
If the drone crashes and after re-starting and trimming, it still is unstable, you have
the option to re-calibrate the drone.
1. Turn on the drone and then the remote and sync.
2. Push and hold the both the throttle and direction stick to the lower right
corners for 2-3 seconds.
3. The lights will flash to indicate that the drone has re-calibrated.
*Allow 15 minutes to pass between full flights as this will give the motors a chance
to cool down. Failure to do so could wear out and shorten the life of the motors.
SYMPTOM
Kaptur
does not
respond
Response to
control inputs
intermittent or
erratic
Kaptur will not
hover or strafe
correctly
HOW TO CHANGE THE BLADES
- All drones have two rotors that spin clockwise
and two rotors that spin counter-clockwise.
- Make sure to place the blades on the correct axis or
they will not spin correctly and the drone will not lift.
- Each blade is marked on its top with A or B. There
may be a number after the letter but you can ignore
the number.
- Make sure to follow the graphic below to see
where to place the blades.
POSSIBLE CAUSE
1. Communication between
controller and aircraft was not
synchronized during set up
2. Battery power depleted on
aircraft, controller or both.
1. Controller battery power
nearly depleted.
1. The aircraft was not
on level ground during
synchronization.
2. Trim settings are incorrect.
POTENTIAL SOLUTION
1. To synchronize, turn on aircraft
first, place it on level ground, and
then turn on controller.
2. Charge aircraft and/or replace
batteries in controller.
1. Replace batteries in controller.
1. Re-synchronize aircraft
and controller.
2. Recalibrate the Altitude Sensor.
A
B
B
A
CAMERA/FRONT
