- Page 1 AERO 2.0 R/C DRONE INSTRUCTION MANUAL...
- Page 3 THANK YOU. Thank you for your purchase of Protocol’s Aero 2.0 R/C Drone. You are about to experience the best of what remote control flight has to offer. We strongly recommend that you take the time to read this manual thoroughly. It contains many tips and instructions on how to get the most out of this aircraft and maintain it for a long life.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Safety & Precautions Parts Remote Battery Charging the Drone Start-Up Procedure Operation Performance Modes Trim Adjustment 360° Flips Other Features Troubleshooting Flying Outdoors Replacement Parts & Limited Warranty... - Page 5 • Never attempt to modify function of vehicle or controller or attempt • repairs using parts other than those supplied by Protocol. Spare parts are available at www.ProtocolNY.com THIS DEVICE USES COMPONENTS THAT OPERATE AT HIGH SPEEDS. AS WITH ANY SUCH DEVICE, USE CAUTION TO OPERATE SAFELY.
- Page 6 PARTS DRONE 1. Canopy 2. Blade Guard 3. Blade 4. Battery Compartment 5. Power Switch...
- Page 7 PARTS REMOTE 12. Emergency Landing (short press) 1. Power Switch /Calibration (long press) 13. Right Trimmer 2. Forward/Backward 3. Bank Left/Right 14. Backward Trimmer 15. Left Trimmer 4. Throttle 5. Turn Left/Right 16. Forward Trimmer 6. Take Off/Landing 7. Compass Mode (Short press) Short press = press &...
-
Page 8: Remote Battery
REMOTE BATTERY INSTALLING THE BATTERIES REMOTE ‘AAA’ BATTERY Please use 3PCS ‘AAA’ batteries and load them per the correct “+” “-” polarity. Please do not mix batteries of different sizes. Remove battery cover from controller. Insert 3 x ‘AAA’ batteries according to indicated polarities. -
Page 9: Charging The Drone
CHARGING THE DRONE BATTERY 1. Make sure the drone is turned off. 2. Disconnect the battery from the drone. 3. Connect the USB charging cable to the battery. 4. Plug the charger into a USB port. The USB light will stay off while charging and will turn on once fully charged. -
Page 10: Start-Up Procedure
START-UP PROCEDURE Before flying, the drone and transmitter must be turned on in sequence and synchronized. 1. Turn on the drone. The lights on both sides of the drone will flash to indicate it’s on. The blue lights are at the front and the yellow lights are at the back. Place it on an even surface in front of you. - Page 11 OPERATION: FLYING THE DRONE TAKE–OFF: 1. Press the take off button. The remote will beep and the drone will hover a few feet off the ground. Then gently advance the throttle to a desired height and release. The drone will hover at that height.* 2.
- Page 12 OPERATION: FLYING THE DRONE COMPASS MODE Users have the option to exit the default orientation (blue lights at the front, yellow lights at the back). In Compass Mode, users can operate the drone without orientation. Regardless of where the drone is pointing, it will turn left or right according to the remote’s command.
- Page 13 OPERATION: FLYING THE DRONE FIRST TIME FLYERS!!! TAKE YOUR TIME! GO SLOW! Practice hovering until you are comfortable with flight before attempting any other maneuvers. Make small movements letting the stick return to the center. If you start to lose control, don’t panic. Just press land. LEFT ROTATION RIGHT ROTATION Pull the throttle left or right,...
-
Page 14: Performance Modes
At higher speeds, the drone will pitch more than at lower speeds. Aero 2.0 is quite fast at its highest speed and requires more piloting skills to fly competently. For safety take time to develop advanced skills by practicing at lower speeds first. -
Page 15: Trim Adjustment
TRIM ADJUSTMENT BACKWARD FORWARD FORWARD/BACKWARD TRIM When the drone drifts forward/backward unintentionally, you can correct it by pressing the opposite trim button until it evens out. Press 1 when drifting backward Press 2 when drifting forward RIGHT LEFT LEFT/RIGHT TRIM When the drone veers left/right unintentionally, you can correct it by pressing the opposite trim button until it evens out. -
Page 16: 360° Flips
360° FLIPS Once you have become skilled with the basics of drone flight, you can try some advanced maneuvers. 1) Make sure the drone is at a height of 10 feet. 2) To flip, press the Flip Button and then push the direction stick in the desired direction. -
Page 17: Other Features
OTHER FEATURES RETURN Press the return button for 1 second and release. The drone will start to fly backwards. To cancel return, press the button again or push the direction stick in any direction. ONE KEY RETURN SPINNING & CIRCLING To spin, press &... -
Page 18: Troubleshooting
TROUBLESHOOTING LOW BATTERY ALARM The lights will flash when the battery is low. Land the drone as soon as possible and recharge the drone. RE-CALIBRATING THE DRONE If the drone crashes and after re-starting and trimming, it still is unstable, you have the option to re-calibrate the drone. - Page 19 Failure to do so could wear out and shorten the life of the motors. SYMPTOM POSSIBLE CAUSE POTENTIAL SOLUTION Aero 2.0 does 1. Communication between 1. To synchronize, turn on aircraft not respond controller and aircraft was not...
-
Page 20: Flying Outdoors
FLYING OUTDOORS HOW TO PREVENT FLY AWAYS To prevent “fly-away” situations (where drones seem to fly away out of control) it is important to first test and practice within close range before letting the drone fly too far away. Each drone is designed to turn off the engines if the radio signal is lost. It is important to know and test the range of your drone before flying. - Page 21 REPLACEMENT PARTS Thank you for your purchase of Protocol’s Aero 2.0 R/C Drone. We know that accidents can sometimes happen and that is why we offer spare parts kits on our website: www.ProtocolNY.com. LIMITED WARRANTY At Protocol, we’re dedicated to bringing you innovative and well-designed products that make living fun and easy.
