Protocol AeroDrone Instruction Manual

Drone with live streaming camera
Hide thumbs

Advertisement

Table of Contents

AERODRONE
DRONE WITH LIVE STREAMING CAMERA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AeroDrone and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Protocol AeroDrone

Summary of Contents for Protocol AeroDrone

  • Page 1 AERODRONE DRONE WITH LIVE STREAMING CAMERA...
  • Page 3 THANK YOU. Thank you for your purchase of Protocol’s AeroDrone with Live Streaming Camera. You are about to experience the best of what remote control flight has to offer. We strongly recommend that you take the time to read this manual thoroughly. It contains many tips and instructions on how to get the most out of this aircraft and maintain it for a long life.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Safety & Precautions Parts Remote Battery Installation Charging the Drone Start-Up Procedure Operation Tips on 360° Flips Speed Modes Trim Adjustment Troubleshooting Flying Outdoors Replacement Parts & Limited Warranty...
  • Page 5 • Never attempte to modify function of vehicle or controller or attempt • repairs using parts other then those supplied by Protocol. Spare parts are available at www.ProtocolNY.com THIS DEVICE USES COMPONETS THAT OPERATE AT HIGH SPEEDS. AS WITH ANY SUCH DEVICE, USE CAUTION TO OPERATE SAFELY.

  • Page 6: Parts

    PARTS Underneath DRONE INSTALLING BLADE GUARDS AND LANDING GEAR 1. Canopy 2. Blade The blade guards and landing gear are 3. Battery Compartment packed separately from the drone. Slide 4. Camera the landing gear and blade guards into 5. Power Switch the corresponding slots on the drone.
  • Page 7 PARTS PHONE MOUNT Slide into tracks and pull up clamp to install phone. REMOTE SPARE PARTS INCLUDED 1. Power Switch Replacement Blades 2. Flip 360° 3. Forward/Backward 4. Bank Left/Right 5. Throttle 6. Turn Left/Right 7. Take Off/Landing 8. Trimmer 9.

  • Page 8: Remote Battery Installation

    REMOTE BATTERY INSTALLATION Unscrew and remove battery cover from controller. Insert 4 x ‘AAA’ batteries according to indicated polarities. Replace and screw back in battery cover. 1. Install batteries carefully. 2. Do not mix old and new batteries. 3. Do not mix different types of batteries.

  • Page 9: Charging The Drone

    CHARGING THE DRONE BATTERY 1. Remove the battery from the drone. 2. Connect the USB charging cable to the battery. 3. Plug the charger into a USB port. The USB light will turn off while charging and will turn on once fully charged. 4.

  • Page 10: Start-Up Procedure

    START-UP PROCEDURE Before flying, the drone and transmitter must be turned on in sequence and synchronized. 1. Turn on the drone and place it on an even surface. The blue lights on the drone are at the front and the yellow are at the back. 2.
  • Page 11 START-UP PROCEDURE COMPASS MODE Users have the option to exit the default orientation (blue lights at the front, yellow lights at the back). In Compass Mode, users can operate the drone without orientation. Regardless of where the drone is pointing, it will turn left or right according to the remote’s command.

  • Page 12: Operation

    OPERATION: FLYING THE DRONE TAKE–OFF: 1. Press the take off button. The remote will beep and the drone will hover a few feet off the ground. Then gently advance the throttle to a desired height and release. The drone will hover at that height.* 2.
  • Page 13 OPERATION: FLYING THE DRONE FIRST TIME FLYERS!!! TAKE YOUR TIME! GO SLOW! Practice hovering until you are comfortable with flight before attempting any other maneuvers. Make small movements letting the stick return to the center. If you start to lose control, don’t panic. Just press land. LEFT RIGHT ROTATION...

  • Page 14: Tips On 360° Flips

    TIPS ON 360° FLIPS Once you have become skilled with the basics of drone flight, you can try some advanced maneuvers. At a height of at least 10 feet, press the Flip button and move the direction lever in any desired direction to execute the flip. 360°...
  • Page 15 TIPS ON 360° FLIPS FORWARD 360° FLIP Push the direction stick forward and the drone will perform a 360° flip in that direction. BACKWARD 360° FLIP Push the direction stick backward and the drone will perform a 360° flip in that direction.

  • Page 16: Speed Modes

    The AeroDrone features three speed modes. Choose the speed based on flight experience and level of comfort. At high speed the drone will pitch more than at low speed. AeroDrone is quite fast at its high speed and requires more piloting skills to fly competently. For safety take time to develop advanced skills by practicing at low speed first.

  • Page 17: Trim Adjustment

    TRIM ADJUSTMENT LEFT RIGHT MOVEMENT MOVEMENT SIDEWAYS TRIM When the drone drifts to the left or right side unintentionally, you can correct it by pressing the trimmer in the opposite direction until it evens out. FORWARD BACKWARD FORWARD/BACKWARD TRIM When the drone drifts forward/backward unintentionally, you can correct it by pressing the trimmer in the opposite direction until it evens out.

  • Page 18: Troubleshooting

    TROUBLESHOOTING RE-CALIBRATING THE ALTITUDE SENSOR If the drone crashes and after re-starting and trimming, it still is unstable, you have the option to re-calibrate the drone. 1. Turn on the drone and then the remote and sync. 2. Press the calibrate button. 3.
  • Page 19 *Allow 15 minutes to pass between full flights as this will give the motors a chance to cool down. Failure to do so could wear out and shorten the life of the motors. SYMPTOM POSSIBLE CAUSE POTENTIAL SOLUTION AeroDrone 1. Communication between 1. To synchronize, turn on aircraft does not controller and aircraft was not...

  • Page 20: Flying Outdoors

    FLYING OUTDOORS HOW TO PREVENT FLY AWAYS To prevent “fly-away” situations (where drones seem to fly away out of control) it is important to first test and practice within close range before letting the drone fly too far away. Each drone is designed to turn off the engines if the radio signal is lost. It is important to know and test the range of your drone before flying.
  • Page 21 REPLACEMENT PARTS Thank you for your purchase of Protocol’s AeroDrone with Live Streaming Camera. We know that accidents can sometimes happen and that is why we offer spare parts kits on our website: ProtocolNY.com. LIMITED WARRANTY At Protocol, we’re dedicated to bringing you innovative and well-designed products that make living fun and easy.
