- Page 1 DRONIUM 3X DRONE WITH LIVE STREAMING CAMERA...
- Page 3 THANK YOU. Thank you for your purchase of Protocol’s Dronium 3X Drone with Live Streaming Camera. You are about to experience the best of what remote control flight has to offer. We strongly recommend that you take the time to read this manual thoroughly.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Safety & Precautions Parts Remote Battery & Blade Guard Installation Charging the Drone Start-Up Procedure Operation Tips on 360° Flips Speed Modes Trim Adjustment Troubleshooting Flying Outdoors Shooting Photo/Video Replacement Parts & Limited Warranty... - Page 5 • Never attempte to modify function of vehicle or controller or attempt • repairs using parts other then those supplied by Protocol. Spare parts are available at www.ProtocolNY.com THIS DEVICE USES COMPONETS THAT OPERATE AT HIGH SPEEDS. AS WITH ANY SUCH DEVICE, USE CAUTION TO OPERATE SAFELY.
-
Page 6: Parts
PARTS DRONE 1. Canopy 2. Blade Guard 3. Blade 4. Battery Compartment 5. Camera 6. ON/OFF Switch... - Page 7 PARTS REMOTE 12. Turn Left/Right 13. Speed Mode Selector 1. 2.4G Antenna 14. Take Off/Landing 2. Power Switch 15. Calibration 3. Trim Forward/Backward 4. Flip 360° SPARE PARTS INCLUDED 5. Forward/Backward 6. Bank Left/Right Replacement Blades Blade Guards 7. Video 8.
-
Page 8: Remote Battery & Blade Guard Installation
REMOTE BATTERY AND BLADE GUARD INSTALLATION Battery cover Unscrew and remove battery cover from controller. Insert 4 x ‘AA’ batteries according to indicated polarities. Replace and screw back in battery cover. 1. Install batteries carefully. 2. Do not mix old and new batteries. 3. -
Page 9: Charging The Drone
CHARGING THE DRONE BATTERY 1. Make sure the drone is turned off. 2. Pull out the cartridge battery from the drone. 3. Connect the USB charging cable to the battery. 4. Plug the charger into a USB port. The USB light will turn off while charging and will turn on once fully charged. -
Page 10: Start-Up Procedure
2. If after 30 seconds, it has not recognized the drone, turn off the controller and repeat Start-Up procedure. 3. If the Dronium 3X is unsteady in flight, it may not have been able to calibrate properly. Power down both drone and remote and restart pre-flight procedure, including re-calibration of the altitude sensor. - Page 11 START-UP PROCEDURE BEFORE STARTING THE ENGINES, CALIBRATE THE ALTITUDE SENSOR. DO THIS BEFORE EACH FLIGHT – EVERY TIME! TO CALIBRATE ALTITUDE SENSOR Press the calibration button once Calibration Button* * Press once to calibrate. Lights will flash quickly during calibration and then go steady when completed.
-
Page 12: Operation
OPERATION: FLYING THE DRONE TAKE–OFF: 1. Press the take off button. The remote will beep and the drone will hover a few feet off the ground. Then gently advance the throttle to a desired height and release. The drone will hover at that height.* 2. - Page 13 OPERATION: FLYING THE DRONE FIRST TIME FLYERS!!! TAKE YOUR TIME! GO SLOW! Practice hovering until you are comfortable with flight before attempting any other maneuvers. Make small movements letting the stick return to the center. If you start to lose control, don’t panic. Just press land. LEFT ROTATION RIGHT ROTATION Pull the throttle left or right,...
-
Page 14: Tips On 360° Flips
TIPS ON 360° FLIPS Once you have become skilled with the basics of drone flight, you can try some advanced maneuvers. At a height of at least 10 feet, press the Flip Mode button and move the direction lever in any desired direction to execute the flip. The remote will beep quickly when you are in stunt mode and will stop beeping once you have executed the flip. - Page 15 OPERATION: FLYING THE DRONE FORWARD 360° FLIP Push the direction stick forward and the drone will perform a 360° flip in that direction. BACKWARD 360° FLIP Push the direction stick backward and the drone will perform a 360° flip in that direction.
-
Page 16: Speed Modes
At higher speeds, the drone will pitch more than at lower speeds. Dronium 3X is quite fast at its highest speed and requires more piloting skills to fly competently. For safety take time to develop advanced skills by practicing at lower speeds first. -
Page 17: Trim Adjustment
TRIM ADJUSTMENT LEFT MOVEMENT RIGHT MOVEMENT SIDEWAYS TRIM When the drone drifts to the left or right side unintentionally, you can correct it by pressing the trim button in the opposite direction until it evens out. BACKWARD FORWARD FORWARD/BACKWARD TRIM When the drone drifts forward/backward unintentionally, you can correct it by pressing the trim button in the opposite direction until it evens out. -
Page 18: Troubleshooting
Failure to do so could wear out and shorten the life of the motors. SYMPTOM POSSIBLE CAUSE POTENTIAL SOLUTION Dronium 3X 1. Communication between 1. To synchronize, turn on aircraft does not controller and aircraft was not... -
Page 19: Flying Outdoors
FLYING OUTDOORS HOW TO PREVENT FLY AWAYS To prevent “fly-away” situations (where drones seem to fly away out of control) it is important to first test and practice within close range before letting the drone fly too far away. Each drone is designed to turn off the engines if the radio signal is lost. It is important to know and test the range of your drone before flying. -
Page 20: Shooting Photo/Video
SHOOTING PHOTO/VIDEO 1. The memory card comes pre-inserted into the camera. SHOOTING PHOTOS AND VIDEO 1. Turn on the drone and sync. 2. Photo: Push the Photo button and the camera will take a photo. The lights on the drone will flash once as it’s taking the picture. 3. - Page 21 REPLACEMENT PARTS Thank you for your purchase of Protocol’s Dronium 3X Drone with Live Streaming Camera. We know that accidents can sometimes happen and that is why we offer spare parts kits on our website: www.ProtocolNY.com. LIMITED WARRANTY At Protocol, we’re dedicated to bringing you innovative and well-designed products that make living fun and easy.
