Step 7; Step 8 - convenience concepts 5 Tier Bookcase with Drawer Assembly Instructions Manual

Step 7

4 X (C)
4 X (D)
2 X (I)
2 X (J)
1.Screw Cam bolts (C) into Middle Panel
2.Connect the 2 assembles together using Cam Bolts
(C) and Cam Locks (D).
ip Bracket (I) to back of unit of using Screws (J).
3.Attach Anti-T

Step 8

2 X (C)
2 X (D)
E
E
4 X (E)
4 X (G)
2 X (H)
2 X (M)
1. Connect Drawer Left 13 & Right 12 Side Panels to Drawer back panel 14 using screw (E).
2. Insert the drawer bottom panel 15.
3. Insert wooden dowels (G) into drawer side panels 12 & 13
4. Screw Cam bolts (C) into Drawer Front Panel 16.
5. Attach drawer front panel to assembly using Cam bolts (C) and Cam Locks (D).
6. Attach handles (M) to drawer front using screw (H).
1
J I
5 .
14
12
H
12
G
D
C
G
J
I
5
C
D
C
D
8
E
E
13
13
D
G
C
G
H
M
16
M
into grooves of drawer assemly
9
C
C
D
D
15
12
13
