Step 5; Step 6 - convenience concepts 5 Tier Bookcase with Drawer Assembly Instructions Manual

1. Screw Cam bolts(C) into Bottom Right Panel 8

Step 5

2. Attach Shelves 4 to Bottom Right Panel 8 using Bolts(A) and Lock Nuts(B).
3. Attach Back Supoprt Bars 10 & 3 to assembly using Cam Bolts (C) and Cam Locks (D).
4 X (A)
4 X (B)
8 X (C)
8 X (D)
* Take extra care with support bars 10 & 3 while they are awaiting step 6.*
* Refer to page 2 for cam lock/bolt assembly.*

Step 6

1. Screw Cam Bolts (C) into bottom left panel 9 .
2. Attach Bottom left panel 9 to assembly
using cam bolts(C),Cam Locks(D),Lock Nuts(B),
and Bolts(A).
4 X (A)
4 X (B)
8 X (C)
8 X (D)
