Sentinel V SC and RT Operation Manual
Table 47. Sentinel V Features Data
Binary Field
Byte
1,2 ID Code
3 Number of Fea-
tures Types
4 Spare
5-37 Features ID #1
38-78 Magic Code #1
79-90 Status #1
86(N-1)+5 Features ID #N
- 86(N-
1)+37
86(N- Magic Code #N
1)+38 -
86(N-
1)+78
86(N- Status #N
1)+79 -
86(N-
1)+90
Description
Stores the Sentinel V – Features Header data identification word 7003
(70 03h). LSB is sent first.
Contains the number of feature data types configured in firmware
Undefined
Unique identifier for the feature, a 33 char null terminated string represent-
ing a V4 GUID. LSB is sent first
Magic code.
12 char null terminated string for the feature state viz. Installed, Activated
and Deactivated
Unique identifier for the feature, a 33 char null terminated string represent-
ing a V4 GUID. LSB is sent first
Magic code.
12 char null terminated string for the feature state viz. Installed, Activated
and Deactivated
