Beam Pattern: CONVEX
Vertical Beam: PISTON
COM: RS-232
Sensors:
Temperature:
Heading/Pitch/Roll:
Pressure:
CPU Firmware: 66.01.00.10
FPGA Version: 2.00.008 year/week 1206 [0x20081206]
Board Serial Number Data:
8E 00 00 01 48 E1 4E 23
19 00 00 00 D7 CE 20 23
76 00 00 01 51 71 B7 23
>
PS3 – Instrument Transformation Matrix
PS3 sends information about the transducer beams. The Sentinel V Real-Time uses this information in its
coordinate-transformation calculations; for example, the output may look like this:
>ps3
Profiling Beams:
Janus Xdcr Type:
Janus Beam Angle (deg)
Janus Beam Freq (Hz)
Janus Beam Dia (mm)
Janus Beam Offset (mm)
Instrument Transformation Matrix:
1.1809 -1.1809 0.0015 -0.0015
-0.0015 0.0015 -1.1883
0.2756 0.2756 0.2760
0.8382 0.8382 -0.8371 -0.8371
Has V-Beam: Yes
VBeam Xdcr Type: Piston
VBeamFreq (Hz) 491520
VBeam Dia (mm) 0
VBeam Offset (mm) 0
>
If the Sentinel V Real-Time needs beam angle corrections, a TRDI calibrated beam angle matrix is loaded
into the instrument. This is done when the instrument is manufactured. For details, download a copy of
the Sentinel V Real-Time Coordinate Transformation booklet (at
PS5 - Health and Environment Monitoring Sensors
The PS5 command reports the value of HEM sensors: S1 (operating time), S2 (over-pressure count), S3
(maximum pressure seen), and S7 (total pressure cycles). The PS5 output will read N/A for the Maximum
pressure seen reading if no pressure was measured/recorded.
PS5
Operating time: 4327.5 hours
Maximum pressure seen: 652.378 dBar
Over-pressure events: 3
Pressure cycles: 25
PS6 – RSSI Calibration
PS6 displays the configured RSSI calibration data, scale and offset, for each beam.
>ps6
Rssi scale/offset:
B1=[1.000 0] B2=[1.000
B3=[1.000 0] B4=[1.000
B5=[1.000 0]
>
Page 226
EAR-Controlled Technology Subject to Restrictions Contained on the Cover Page.
A/D SENSOR
TCM Prime
KELLER30
DSP-72D-2001-01E3
XDR-71D-2000-41B
TRX-72D-2012-03A00
4
Piston
25
491520
0
0
1.1883
0.2760
0]
0]
